FRONT DRIVE SHAFT FAX-21 < DISASSEMBLY AND ASSEMBLY > C E F G H I J K L M A B FAX N O P 4. Put matching marks on slide joint housing and shaft before separating slide joint housing. joint housing. 6. Put matching marks on spider assembly and shaft. 7. Remove snap ring using a suitable tool, then remove spider assembly from shaft. 8. Remove boot from shaft. Wheel Side 1. Mount the front drive shaft in a vise. CAUTION: When mounting shaft in a vise, always use copper or aluminum plates between vise and shaft. 2. Remove boot bands and slide the boot back. into threaded part of joint sub-assembly. Pull joint sub-assembly out of shaft. CAUTION: • Align sliding hammer or suitable tool and drive shaft then remove joint sub-assembly by pulling directly. • If joint sub-assembly cannot be removed after five or more unsuccessful attempts, replace the entire drive shaft assembly. 4. Remove boot from shaft. Support Bearing SFA476 SFA963 SFA612 SDIA0606E |
