EXT-40 < ON-VEHICLE REPAIR > [SEDAN] FENDER PROTECTOR FENDER PROTECTOR Removal and Installation INFOID:0000000004205940 REMOVAL 1. Remove the engine under cover. Refer to EXT-34, "Removal and Installation" . 2. Remove the screw from center mudguard. INSTALLATION Installation is in the reverse order of removal. 1. Fender protector 2. Fender protector side cover A. J-clips B. Clips C. Center mudguard screw Vehicle front a. Sheet metal nut ALKIA0005ZZ |
