P0850 PNP SWITCH EC-365 < COMPONENT DIAGNOSIS > [QR25DE FOR CALIFORNIA] C D E F G H I J K L M A EC N P O P0850 PNP SWITCH Description INFOID:0000000004349403 When the shift lever position is P or N (CVT), Neutral position (M/T), park/neutral position (PNP) switch is ON. ECM detects the position because the continuity of the line (the ON signal) exists. DTC Logic INFOID:0000000004349404 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1. INSPECTION START Do you have CONSULT-III? YES >> GO TO 2. NO >> GO TO 5. 2. PRECONDITIONING If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test. >> GO TO 3. 3. CHECK PNP SWITCH FUNCTION With CONSULT-III 1. Turn ignition switch ON. 2. Select “P/N POSI SW” in “DATA MONITOR” mode with CONSULT-III. Then check the “P/N POSI SW” sig- nal under the following conditions. Is the inspection result normal? YES >> GO TO 4. NO >> Go to 4. PERFORM DTC CONFIRMATION PROCEDURE 1. Select “DATA MONITOR” mode with CONSULT-III. 2. Start engine and warm it up to normal operating temperature. 3. Maintain the following conditions for at least 50 consecutive seconds. CAUTION: Always drive vehicle at a safe speed. DTC No. Trouble diagnosis name DTC detecting condition Possible cause P0850 Park/neutral position The signal of the park/neutral position (PNP) • Harness or connectors [The park/neutral position (PNP) switch • Park/neutral position (PNP) switch Position (Shift lever) Known-good signal N or P position (CVT) ON Except above position OFF ENG SPEED CVT: 1,300 - 6,375 rpm COOLAN TEMP/S More than 70 °C (158°F) |
