BCM (BODY CONTROL MODULE) DEF-31 < ECU DIAGNOSIS > C D E F G H I J K M A B DEF N O P 62 4 (B/Y) Ground Front outside handle Output When the front When Intelligent Key is in When Intelligent Key is not 63 4 (LG) Ground Front outside handle Output When the front When Intelligent Key is in When Intelligent Key is not 64 4 (V) Ground Front outside handle Output When the front When Intelligent Key is in When Intelligent Key is not Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output (+) (-) JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB |
