BR-46
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General Specifications
INFOID:0000000004204203
Unit: mm (in)
Brake Pedal
INFOID:0000000004204204
Front brake
Brake model
Kiriu
Cylinder bore diameter
57.2 (2.25)
Pad length
× width × thickness
126.5
× 52 × 11 (4.98 × 2.047 × 0.433)
Rotor outer diameter
× thickness
296
× 26 (11.65 × 1.024)
Rear brake
Brake model
Kiriu
Cylinder bore diameter
34.93 (1.375)
Pad length
× width × thickness
83
× 33 × 8.5 (3.268 × 1.299 × 0.335)
Rotor outer diameter
× thickness
292
× 9 (11.50 × 0.354)
Master cylinder
Cylinder bore diameter
25.4 (1)
Control valve
Valve model
Electric brake force distribution
Brake booster
Booster model
Bosch
Diaphragm diameter
280 (11)
Recommended brake fluid
DOT 3
Brake pedal height (H)
(from dash lower panel top surface)
CVT
190.7 - 202.7 mm (7.51 - 7.98 in)
M/T
181.3 -193.3 mm (7.14 - 7.61 in)
Brake pedal full stroke (S)
[under a force of 490 N (50 kg-f, 110 lb-f) with engine running]
CVT
130 mm (5.12 in)
M/T
130 mm (5.12 in)
Clearance between stopper bracket and threaded end of the stop lamp switch
and ASCD cancel switch (C
1
and C
2
)
0.74 - 1.96 mm (0.0291 - 0.0772 in)
AWFIA0433ZZ
