SEC-594

< SYMPTOM DIAGNOSIS >

[SEDAN WITHOUT INTELLIGENT KEY]

VEHICLE SECURITY SYSTEM SYMPTOMS

VEHICLE SECURITY SYSTEM SYMPTOMS

Symptom Table

INFOID:0000000004499245

*: Check that the system is in the armed phase.

Procedure

Diagnostic procedure

Refer to page

Symptom

1

Vehicle security sys-
tem cannot be set by
····

Door switch

Check door switch

DLK-293

Trunk

Check trunk room lamp switch

DLK-316

Door outside key

Check key cylinder switch

DLK-305

Keyfob

Check keyfob.

DLK-526

—

Check Intermittent Incident

GI-42

Security indicator does not turn ON.

Check vehicle security indicator

SEC-514

Check Intermittent Incident

GI-42

2

* Vehicle security
system does not
sound alarm when ····

Any door is opened.

Check door switch

DLK-293

Check Intermittent Incident

GI-42

3

Vehicle security
alarm does not acti-
vate.

Horn alarm

Check horn

DLK-344

Check Intermittent Incident

GI-42

Head lamp alarm

Check head lamp alarm

SEC-512

Check Intermittent Incident

GI-42

4

Vehicle security sys-
tem cannot be can-
celed by ····

Door outside key

Check key cylinder switch

SEC-507

Check Intermittent Incident

GI-42

Keyfob

Check keyfob

DLK-526

Check Intermittent Incident

GI-42

NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS SYMPTOMS

SEC-595

< SYMPTOM DIAGNOSIS >

[SEDAN WITHOUT INTELLIGENT KEY]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS SYMPTOMS

Symptom Table

INFOID:0000000004499246

Security indicator does not turn ON or flash.

CAUTION:

• Follow Trouble Diagnosis Flowchart referring to “

SEC-411, "Work Flow"

”. Determine malfunctioning

condition before performing this diagnosis.

• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagno-

sis.

• Check systems shown in the “Action” column in this order.

CONDITIONS OF VEHICLE (OPERATING CONDITIONS)

• Keyfob is not inserted into key slot.

• Engine switch is not depressed.

Action

Reference page

1. Check vehicle security indicator

SEC-514

2. Check Intermittent Incident

GI-42

SEC-596

< ON-VEHICLE REPAIR >

[SEDAN WITHOUT INTELLIGENT KEY]

KEY SLOT

ON-VEHICLE REPAIR

KEY SLOT

Removal and Installation

INFOID:0000000004499249

REMOVAL

1. Remove the instrument lower panel LH. Refer to

IP-12, "Removal and Installation"

.

2. Disconnect key slot connector.
3. Remove the key slot screw (A), and then remove key slot (1)

from instrument lower panel LH (2).

INSTALLATION

Installation is in the reverse order of removal.

AWKIA1495ZZ

PUSH BUTTON IGNITION SWITCH

SEC-597

< ON-VEHICLE REPAIR >

[SEDAN WITHOUT INTELLIGENT KEY]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

PUSH BUTTON IGNITION SWITCH

Removal and Installation

INFOID:0000000004499250

REMOVAL

1. Remove the cluster lid A assembly. Refer to

IP-12, "Removal and Installation"

.

2. Release the pawls (A) and remove the push-button ignition

switch (1) from cluster lid A.

INSTALLATION

Installation is in the reverse order of removal.

JMKIA0167ZZ
