SEC-578 < ECU DIAGNOSIS > [SEDAN WITHOUT INTELLIGENT KEY] IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) IHBT RLY -REQ Ignition switch ON Off At engine cranking On ST/INHI RLY Ignition switch ON Off At engine cranking ST →INHI The status of starter relay or starter control relay cannot be recognized by UNKWN DETENT SW Ignition switch ON • Press the selector button with CVT selector lever in P position • CVT selector lever in any posi- tion other than P Off Release the CVT selector button with CVT selector lever in P position On S/L RLY -REQ None of the conditions below are present Off • Open the driver door after the ignition switch is turned OFF (for a few seconds) • Press the push-button ignition switch when the steering lock is activat- ed • Depress the clutch pedal when the steering lock is activated On S/L STATE Steering lock is activated LOCK Steering lock is deactivated UNLK [DTC B210A] is detected UNKWN DTRL REQ NOTE: Off OIL P SW Ignition switch OFF, ACC or engine running Open Ignition switch ON Close THFT HRN REQ Not operated Off • Panic alarm is activated TEM On HORN CHIRP Not operated Off Door locking with Intelligent Key (horn chirp mode) On CRNRNG LMP REQ NOTE: Off Monitor Item Condition Value/Status |
