Nissan Altima L32. Manual - part 1296

SEC-334

< ECU DIAGNOSIS >

[SEDAN WITH INTELLIGENT KEY]

BCM (BODY CONTROL MODULE)

51

(L/W)

Ground

Combination switch
OUTPUT 1

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

0V

Front wiper switch HI
(Wiper intermittent dial 4)

10.7V

Any of the conditions below
with all switch OFF
• Wiper intermittent dial 1
• WIper intermittent dial 2
• Wiper intermittent dial 3
• Wiper intermittent dial 6
• Wiper intermittent dial 7

52

(G/B)

Ground

Combination switch
OUTPUT 2

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

0V

Front washer switch ON
(Wiper intermittent dial 4)

10.7V

Any of the conditions below
with all switch OFF
• Wiper intermittent dial 1
• WIper intermittent dial 5
• Wiper intermittent dial 6

53

(LG/

R)

Ground

Combination switch
OUTPUT 3

Output

Combination
switch
(Wiper intermit-
tent dial 4)

All switch OFF

0V

Front wiper switch INT

10.7V

Front wiper switch LO

Lighting switch AUTO

54

(G/Y)

Ground

Combination switch
OUTPUT 4

Output

Combination
switch
(Wiper intermit-
tent dial 4)

All switch OFF

0V

Front fog lamp switch ON

10.7V

Lighting switch 2ND

Lighting switch flash-to-
pass

Turn signal switch LH

55

(BR/

W)

Ground Front blower monitor

Input

Front blower mo-
tor switch

ON

Battery voltage

OFF

0V

56

2

(L/B)

Ground

Front door lock as-
sembly LH (key cylin-
der switch) (lock)

Input

Front door lock
assembly LH (key
cylinder switch)

OFF (neutral)

5V

ON (lock)

0V

57

(W)

Ground

Tire pressure warn-
ing check switch

Input

—

5V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JPMIA0032GB

JPMIA0033GB

JPMIA0034GB

JPMIA0035GB

BCM (BODY CONTROL MODULE)

SEC-335

< ECU DIAGNOSIS >

[SEDAN WITH INTELLIGENT KEY]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

58

(SB)

Ground Front door LH switch

Input

Front door LH
switch

OFF (front door LH
CLOSE)

11.8V

ON (front door LH OPEN)

0V

59

(G/R)

Ground

Rear window defog-
ger relay

Output

Rear window de-
fogger

Active

Battery voltage

Not activated

0V

60

(B/R)

Ground

Front console anten-
na 2 (-)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

61

(W/R)

Ground

Center console an-
tenna 2 (+)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JPMIA0011GB

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

SEC-336

< ECU DIAGNOSIS >

[SEDAN WITH INTELLIGENT KEY]

BCM (BODY CONTROL MODULE)

62

4

(B/Y)

Ground

Front outside handle
RH antenna (-)

Output

When the front
door RH request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

63

4

(LG)

Ground

Front outside handle
RH antenna (+)

Output

When the front
door RH request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

64

4

(V)

Ground

Front outside handle
LH antenna (-)

Output

When the front
door LH request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

BCM (BODY CONTROL MODULE)

SEC-337

< ECU DIAGNOSIS >

[SEDAN WITH INTELLIGENT KEY]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

65

4

(P)

Ground

Front outside handle
LH antenna (+)

Output

When the front
door LH request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

66

(R)

Ground

Instrument panel an-
tenna (-)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

67

(G)

Ground

Instrument panel an-
tenna (+)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB
