SEC-306 < COMPONENT DIAGNOSIS > [SEDAN WITH INTELLIGENT KEY] B2619 BCM B2619 BCM Description INFOID:0000000004206276 BCM requests IPDM E/R to supply power to steering lock unit. After receiving the power, the steering lock unit transmits an ON signal to BCM. DTC Logic INFOID:0000000004206277 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1. PERFORM DTC CONFIRMATION PROCEDURE 1. Press the push-button ignition switch under the following conditions and wait for at least 1 second. - CVT selector lever is in the P position - Do not depress brake pedal 2. Check “Self diagnostic result” with CONSULT-III. YES >> Refer to SEC-306, "Diagnosis Procedure" NO >> Inspection End. Diagnosis Procedure INFOID:0000000004206278 1. INSPECTION START 1. Turn ignition switch ON. 2. Check “Self diagnostic result” with CONSULT-III. 3. Touch “ERASE”. 4. Perform DTC Confirmation Procedure. Is the DTC B2619 displayed again? YES >> Replace BCM. Refer to BCS-96, "Removal and Installation" NO >> Inspection End. DTC No. Trouble diagnosis name DTC detecting condition Possible cause B2619 BCM BCM detects a mismatch between the power sup- • BCM |
