BCM (BODY CONTROL MODULE) PWC-255 < ECU DIAGNOSIS > [LH&RH FRONT ANTI-PINCH-COUPE] C D E F G H I J L M A B PWC N O P 76 (R/G) Ground Combination switch Input Combination All switch OFF 1.4V Lighting switch high-beam 1.3V Lighting switch 2ND 1.3V Any of the conditions below 1.3V 77 (BR) Ground Engine switch (push Input Engine switch Pressed 0V Not pressed Battery voltage 78 (P) Ground CAN-L Input/ Output — — 79 (L) Ground CAN-H Input/ Output — — 80 (R/L) Ground Key slot illumination Output Key slot illumina- OFF 0V Blinking 6.5V ON Battery voltage Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output (+) (-) JPMIA0041GB JPMIA0036GB JPMIA0037GB JPMIA0040GB JPMIA0015GB |
