Nissan Altima L32. Manual - part 1114
POWER WINDOW MAIN SWITCH
PWC-223
< ECU DIAGNOSIS >
[LH&RH FRONT ANTI-PINCH-COUPE]
C
D
E
F
G
H
I
J
L
M
A
B
PWC
N
O
P
12
(Y/G)
Ground Power window serial link
Input/
Output
IGN SW ON or power win-
dow timer operating.
13
(G/W)
2
Encoder pulse signal 2
Input
When power window mo-
tor operates.
14
(W/B)
Ground Encoder ground
—
—
0
15
(B)
Ground Ground
—
—
0
Terminal No.
Description
Condition
Voltage [V]
(Approx.)
+
–
Signal name
Input/
Output
JPMIA0013GB
JMKIA0070GB
