Nissan Altima L32. Manual - part 56

AV-216

< ON-VEHICLE REPAIR >

[BOSE AUDIO WITHOUT NAVIGATION]

BOSE SPEAKER AMP

BOSE SPEAKER AMP

Removal and Installation - Coupe

INFOID:0000000004206493

REMOVAL

1. Disconnect the negative battery terminal.
2. Remove the trunk floor carpet and spare tire cover. Refer to

INT-23, "Removal and Installation"

.

3. Remove the RH trunk floor spacer.
4. Remove the Bose speaker amp. screws (A), then disconnect the

Bose speaker amp. connectors (B) and remove the Bose

speaker amp. (1).

INSTALLATION

Installation is in the reverse order of removal.

Removal and Installation - Sedan

INFOID:0000000004206494

REMOVAL

1. Disconnect the negative battery terminal.
2. Open the trunk lid.
3. Remove the Bose speaker amp. screws (A), then disconnect the

Bose speaker amp. connectors (B) and remove the Bose

speaker amp. (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0918ZZ

ALNIA1020ZZ

AV

FRONT TWEETER

AV-217

< ON-VEHICLE REPAIR >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

 FRONT TWEETER

Removal and Installation

INFOID:0000000004206496

REMOVAL

1. Remove the front pillar finisher. Refer to

INT-20, "Removal and Installation"

 (coupe) and

INT-42, "Removal

and Installation"

 (sedan).

2. Remove tweeter speaker grille. Refer to

IP-12, "Removal and Installation"

.

3. Remove the tweeter speaker screws (A), disconnect the tweeter

speaker connector and remove the tweeter speaker (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0050ZZ

AV-218

< ON-VEHICLE REPAIR >

[BOSE AUDIO WITHOUT NAVIGATION]

CENTER SPEAKER

CENTER SPEAKER

Removal and Installation

INFOID:0000000004206497

REMOVAL

1. Remove the center speaker grille. Refer to

IP-12, "Removal and Installation"

.

2. Remove the center speaker screws (A), then pull out the center

speaker (1), then disconnect the center speaker connector and

remove the center speaker (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0053ZZ

AV

FRONT DOOR SPEAKER

AV-219

< ON-VEHICLE REPAIR >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

FRONT DOOR SPEAKER

Removal and Installation

INFOID:0000000004206498

REMOVAL

1. Remove the front door finisher. Refer to

INT-12, "Removal and Installation"

 (coupe) and

INT-34, "Removal

and Installation"

 (sedan).

2. Remove the front door speaker screws (A), then disconnect the

front door speaker connector and remove the front door speaker

(1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0040ZZ
