Preliminary Check Check brake fluid level in reservoir ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Low fluid level may indicate brake pad Check brake line for leakage. OK E NG Repair. F Check brake booster for operation and air OK E NG Replace. F Check brake pads, rotor and drums. OK E NG Replace. Check brake fluid level in reservoir tank. OK E NG Fill up brake fluid. Check warning lamp(s) or warning sound OK E NG Check fuse, warning lamp Check warning lamp(s) for deactivation OK E NG Go to Self-diagnosis, Drive vehicle at speeds over 30 km/h (19 Ensure warning lamp(s) remain(s) off OK E NG Go to Self-diagnosis, END SBR451D SBR389C SBR058C SBR059C YBR266 H H H H H H H H H TROUBLE DIAGNOSES BR-66 |
