Nissan Terrano r20e. Manual - part 229
I
Before reinstalling wiper arm, clean up the pivot area as
illustrated. This will reduce possibility of wiper arm loose-
ness.
Washer Nozzle Adjustment
I
Adjust washer nozzle with suitable tool as shown in the figure
at left.
Adjustable range: ±10°
Check Valve
I
A check valve is provided in the washer fluid line. Be careful not
to connect check valve to washer tube in the wrong direction.
SEL024J
SEL241P
SEL411H
WIPER AND WASHER
Installation (Cont’d)
EL-99
