Description The ECM consists of a microcomputer and connectors for signal On Board Diagnosis Logic Malfunction is detected when ... Check Items (Possible Cause) I ECM input signal processing function is malfunctioning. I ECM DTC Confirmation Procedure WITH CONSULT-II 1) Turn ignition switch “ON”. turn “ON”. 4) If DTC is detected, go to “Diagnostic Procedure”, EC-214. WITHOUT CONSULT-II 1) Turn ignition switch “ON” and wait at least 2 seconds. turn “ON”. 3) Perform “Diagnostic Test Mode II (Self-diagnostic results)” with ECM. 4) If DTC is detected, go to “Diagnostic Procedure”, EC-214. SEC220B SEF817Y DTC 0903 ECM 15 ZD30DDTi EC-213 |
