SEC-36 < DTC/CIRCUIT DIAGNOSIS > VEHICLE SECURITY INDICATOR 3. Check continuity between BCM connector (A) M18 terminal 23 and security indicator lamp harness connector (B) M24 terminal 28. 4. Check continuity between BCM connector (A) M18 terminal 23 and ground. Is the inspection result normal? YES >> Check the following: • 10A fuse [No. 19, located in fuse block (J/B)] • Harness for open or short between security indicator lamp and fuse NO >> Repair or replace harness. 23 - 28 : Continuity should exist. 23 - Ground : Continuity should not exist. LIIA2253E |
