EM-128 < SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) Unit: mm (in) *: Actual clearance Connecting Rod Bearing *: Always check with the Parts Department for the latest parts information. Undersize Unit: mm (in) Connecting Rod Bearing Oil Clearance Unit: mm (in) *: Actual clearance Items Standard Limit Main bearing oil clearance No.1 and 5 0.001 - 0.011 (0.00004 - 0.0004)* 0.021 (0.0008) No.2, 3 and 4 0.007 - 0.017 (0.0003 - 0.0007)* 0.027 (0.0011) Grade number* Thickness “T” mm (in) Identification color (mark) 0 1.500 - 1.503 (0.0591 - 0.0592) Black 1 1.503 - 1.506 (0.0592 - 0.0593) Brown 2 1.506 - 1.509 (0.0593 - 0.0594) Green 3 1.509 - 1.512 (0.0594 - 0.0595) Yellow Undersize Thickness Crank pin journal diameter “Dp” 0.25 (0.0098) 1.627 - 1.635 (0.0641 - 0.0644) Grind so that bearing clearance is the specified value. Items Standard Limit Connecting rod bearing oil clearance 0.020 - 0.039 (0.0008 - 0.0015)* 0.055 (0.0022) |
