P0420, P0430 THREE WAY CATALYST FUNCTION EC-281 < DTC/CIRCUIT DIAGNOSIS > [VK56DE] C D E F G H I J K L M A EC N P O If the 1st trip DTC is detected, go to . Overall Function Check INFOID:0000000009886690 Use this procedure to check the overall function of the three way catalyst (manifold). During this check, a 1st trip DTC might not be confirmed. WITH GST 1. Start engine and warm it up to the normal operating temperature. [HO2S2 (bank 1) signal], 74 [HO2S2 (bank 2) signal] and ground. 7. Keep engine speed at 2,500 rpm constant under no load. onds. If the voltage fluctuation cycle takes less than 5 seconds, go to • 1 cycle: 0.6 - 1.0 → 0 - 0.3 → 0.6 - 1.0 Diagnosis Procedure INFOID:0000000009886691 1. CHECK EXHAUST SYSTEM Visually check exhaust tubes and muffler for dent. OK >> GO TO 2. NG >> Repair or replace. 2. CHECK EXHAUST GAS LEAK 1. Start engine and run it at idle. 2. Listen for an exhaust gas leak before the three way catalyst (manifold). OK or NG OK >> GO TO 3. NG >> Repair or replace. 3. CHECK INTAKE AIR LEAK Listen for an intake air leak after the mass air flow sensor. OK >> GO TO 4. NG >> Repair or replace. 4. CHECK IGNITION TIMING Check the following items. Refer to . PBIB2056E PBIB1216E |
