Nissan Quest E52. Manual - part 443

DLK-486

< REMOVAL AND INSTALLATION >

DOOR SWITCH

DOOR SWITCH

Removal and Installation

INFOID:0000000009649495

REMOVAL

Remove the TORX bolt (A), and then remove door switch (1).

INSTALLATION

Install in the reverse order of removal.

JMKIA2173ZZ

DOOR REQUEST SWITCH

DLK-487

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

DOOR REQUEST SWITCH

DRIVER SIDE

DRIVER SIDE : Removal and Installation

INFOID:0000000009649496

REMOVAL

Remove the driver side outside handle. Refer to

DLK-464, "OUTSIDE HANDLE : Removal and Installation"

.

INSTALLATION

Install in the reverse order of removal.

PASSENGER SIDE

PASSENGER SIDE : Removal and Installation

INFOID:0000000009649497

REMOVAL

Remove the passenger side outside handle. Refer to

DLK-464, "OUTSIDE HANDLE : Removal and Installa-

tion"

.

INSTALLATION

Install in the reverse order of removal.

BACK DOOR

BACK DOOR : Removal and Installation

INFOID:0000000009649498

REMOVAL

Remove the back door finisher. Refer to

EXT-47, "Removal and Installation"

.

INSTALLATION

Install in the reverse order of removal.

DLK-488

< REMOVAL AND INSTALLATION >

INSIDE KEY ANTENNA

INSIDE KEY ANTENNA

INSTRUMENT CENTER

INSTRUMENT CENTER : Removal and Installation

INFOID:0000000009649499

REMOVAL

1.

Remove the instrument lower center panel. Refer to

IP-14, "Removal and Installation"

.

2.

Remove the inside key antenna (instrument center) mounting
screw (A), and then remove inside key antenna (instrument cen-
ter) (1).

CAUTION:

Be careful not to drop mounting screw (A) into instrument
panel.

INSTALLATION

Install in the reverse order of removal.

CONSOLE

CONSOLE : Removal and Installation

INFOID:0000000009649500

REMOVAL

1.

Remove the console body assembly. Refer to

IP-28, "Removal and Installation"

.

2.

Remove the inside key antenna (console) mounting screw (A),
and then remove inside key antenna (console) (1).

INSTALLATION

Install in the reverse order of removal.

LUGGAGE ROOM

LUGGAGE ROOM : Removal and Installation

INFOID:0000000009649501

REMOVAL

1.

Remove the rear floor carpet. Refer to

INT-31, "REAR FLOOR CARPET : Removal and Installation"

.

JMKIA8167ZZ

JMKIA6040ZZ

INSIDE KEY ANTENNA

DLK-489

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

2.

Remove the inside key antenna (luggage room) mounting screw
(A), and then remove inside key antenna (luggage room) (1).

INSTALLATION

Install in the reverse order of removal.

JMKIA6042ZZ
