Nissan Quest E52. Manual - part 111

AV

BOSE AMP.

AV-323

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

BOSE AMP.

Reference Values

INFOID:0000000009652146

TERMINAL LAYOUT

PHYSICAL VALUES

JSNIA1223ZZ

Terminal

(Wire color)

Description

Condition

Standard

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(W)

2

(B)

Sound signal front
squawker LH

Output

Igni-

tion

switc

h ON

Sound output

Outputs wave-
form synchronized
with sound.

4

(BR)

3

(Y)

Sound signal front
squawker RH

Output

Igni-

tion

switc

h ON

Sound output

Outputs wave-
form synchronized
with sound.

10

(SB)

7

(B)

12

(B)

Battery power sup-
ply

Input

Igni-

tion

switc

h

OFF

—

9.0 – 16.0 V

Battery power supply

11

(G)

7

(B)

12

(B)

Battery power sup-
ply

Input

Igni-

tion

switc

h

OFF

—

9.0 – 16.0 V

Battery power supply

13

(R)

8

(G)

Sound signal
woofer

Output

Igni-

tion

switc

h ON

Sound output

Outputs wave-
form synchronized
with sound.

SKIB3609E

SKIB3609E

SKIB3609E

AV-324

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

BOSE AMP.

14

(L)

9

(P)

Sound signal slide
door speaker RH

Output

Igni-

tion

switc

h ON

Sound output

Outputs wave-
form synchronized
with sound.

16

(Y)

17

(BR)

Sound signal lug-
gage squawker

Output

Igni-

tion

switc

h ON

Sound output

Outputs wave-
form synchronized
with sound.

18

(BR)

19

(G)

Sound signal front
door woofer LH

Output

Igni-

tion

switc

h ON

Sound output

Outputs wave-
form synchronized
with sound.

20

(LG)

7

(B)

12

(B)

Amp. ON signal

Input

Igni-

tion

switc

h

ACC

—

6.5 V or more

12.0 V

24

(R)

23

(L)

Sound signal rear
LH

Input

Igni-

tion

switc

h ON

Sound output

Waveform accord-
ing to sound signal
is input.

26

(BR)

25

(Y)

Sound signal rear
RH

Input

Igni-

tion

switc

h ON

Sound output

Waveform accord-
ing to sound signal
is input.

28

(L)

15

(R)

Sound signal slide
door speaker LH

Output

Igni-

tion

switc

h ON

Sound output

Outputs wave-
form synchronized
with sound.

Terminal

(Wire color)

Description

Condition

Standard

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV

BOSE AMP.

AV-325

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

29

(V)

30

(P)

Sound signal cen-
ter squawker

Output

Igni-

tion

switc

h ON

Sound output

Outputs wave-
form synchronized
with sound.

31

(L)

32

(R)

Sound signal front
door woofer RH

Output

Igni-

tion

switc

h ON

Sound output

Outputs wave-
form synchronized
with sound.

33

(V)

34

(G)

Sound signal front
RH

Input

Igni-

tion

switc

h ON

Sound output

Waveform accord-
ing to sound signal
is input.

35

(W)

36

(B)

Sound signal front
LH

Input

Igni-

tion

switc

h ON

Sound output

Waveform accord-
ing to sound signal
is input.

Terminal

(Wire color)

Description

Condition

Standard

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV-326

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

SATELLITE RADIO TUNER

SATELLITE RADIO TUNER

Reference Value

INFOID:0000000009652147

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0010ZZ

Terminal

(Wire color)

Description

Condition

Standard

Reference value

(Approx.)

+

–

Signal name

Input/

Output

2

(W)

1

(B)

Satellite radio
sound signal LH

Output

Ignition

switch

ON

When satellite radio
mode is selected.

Outputs
waveform
synchronized
with sound.

4

(G)

3

(R)

Satellite radio
sound signal RH

Output

Ignition

switch

ON

When satellite radio
mode is selected.

Outputs
waveform
synchronized
with sound.

5

—

Shield

—

—

—

—

—

6

—

Shield

—

—

—

—

—

8

(R/L)

15

(B)

Request signal
(SAT TO CONT)

Output

Ignition

switch

ON

When satellite radio
mode is selected.

Waveform of
0.5 - 7.0 V is
Output.

9

(B/R)

15

(B)

Communication
signal
(SAT TO CONT)

Output

Ignition

switch

ON

When satellite radio
mode is selected.

Waveform of
0.5 - 7.0 V is
Output.

SKIB3609E

SKIB3609E

SKIA9299J

PKIB5039J
