DLK-286

< REMOVAL AND INSTALLATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

FRONT DOOR

2. Loosen door hinge nuts on door side.
3. Adjust the surface height of front door according to the specifications provided.
4. Temporarily tighten door hinge nuts on door side.
5. Loosen door hinge bolts on body side.
6. Raise or lower the front door at rear end to adjust clearance of the front door according to the specifica-

tions provided.

7. After adjustment tighten bolts and nuts to the specified torque.

CAUTION:

• Check door hinge rotating point for poor lubrication. If necessary, apply body a suitable multi-

purpose grease.

• After adjusting, apply touch-up paint (body color) onto the heads of hinge bolts and nuts.

8. Install front fender. Refer to refer to

DLK-281, "FRONT FENDER : Removal and Installation"

.

DOOR STRIKER ADJUSTMENT

Adjust door striker so that it becomes parallel with door lock insertion direction.

DOOR STRIKER
DOOR STRIKER : Removal and Installation

INFOID:0000000009268989

REMOVAL

Remove striker bolts and remove front door striker.

INSTALLATION

Installation is in the reverse order of removal.

CAUTION:

• After installation, check front door open/close, lock/unlock operation.

• After installation, perform the front door adjustment procedure. Refer to

DLK-285, "DOOR ASSEM-

BLY : Adjustment"

.

DOOR HINGE
DOOR HINGE : Removal and Installation

INFOID:0000000009268990

REMOVAL

CAUTION:

• Use two people when removing or installing front door due to its heavy weight

• When removing and installing front door assembly, support the door using a suitable tool.

• Use shops cloths to protect surrounding components from damage during removal and installation

of front door assembly.

1. Remove front fender. Refer to

DLK-281, "FRONT FENDER : Removal and Installation"

.

2. Remove front door assembly. Refer to

DLK-283, "DOOR ASSEMBLY : Removal and Installation"

.

3. Remove front door hinge bolts (body side) and remove front door hinge.

INSTALLATION

Installation is in the reverse order of removal.

CAUTION:

• Apply anticorrosive agent onto the hinge mating surface.

• Perform the front door adjustment procedure. Refer to

DLK-285, "DOOR ASSEMBLY : Adjustment"

.

• After adjusting, apply touch-up paint (the body color) to the head of door hinge nuts.

FRONT DOOR

DLK-287

< REMOVAL AND INSTALLATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

• Check door hinge rotating point for poor lubrication. If neces-

sary, apply a suitable multi-purpose grease.

DOOR CHECK LINK
DOOR CHECK LINK : Removal and Installation

INFOID:0000000009268991

REMOVAL

1. Fully close the front door window.
2. Remove front door finisher. Refer to

INT-15, "Removal and Installation"

.

3. Remove front door speaker bolts.
4. Disconnect harness connector from front door speaker and remove.
5. Remove door check link bolt from body.
6. Remove door check link bolts on door panel.
7. Remove door check link (1) through the hole in door panel (2).

INSTALLATION

Installation is in the reverse order of removal.

CAUTION:

• After installation, check rear door open/close operation.

• Check door check link rotating point for poor lubrication. If

necessary, apply a suitable multi-purpose grease.

JMKIA8072ZZ

JMKIA8073ZZ

JMKIA8074ZZ

DLK-288

< REMOVAL AND INSTALLATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

REAR DOOR

REAR DOOR

Exploded View

INFOID:0000000009268992

DOOR ASSEMBLY
DOOR ASSEMBLY : Removal and Installation

INFOID:0000000009268993

CAUTION:

• Use two people when removing or installing rear door due to its heavy weight.

• When removing and installing rear door assembly, support door using a suitable tool.

• Use shop cloths to protect surrounding components from damage during removal and installation of

front door assembly.

REMOVAL

1. Remove rear door harness grommet (1) from body side outer

(2), and then pull out rear door harness.

1.

Rear door panel

2.

Grommet

3.

Striker bolt

4.

Door striker

5.

Bumper rubber

6.

Sealing screen (lower) (without door
speaker)

7.

Door check link

8.

Door hinge (lower)

9.

Door hinge (upper)

AWKIA1920GB

JMKIA8083ZZ

REAR DOOR

DLK-289

< REMOVAL AND INSTALLATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

2. Disconnect the harness connector (A) from rear door harness.

3. Remove door check link bolts from body.
4. Remove door hinge nuts (door side) and rear door assembly.

INSTALLATION

Installation is in the reverse order of removal.

CAUTION:

• Apply anticorrosive agent onto the hinge mating surface.

• After installation, check rear door open/close, lock/unlock operation.

• Check door hinge rotating point for poor lubrication. If necessary, apply a suitable multi-purpose

grease.

• After installation, perform the rear door adjustment procedure. Refer to

DLK-290, "DOOR ASSEMBLY

: Adjustment"

.

• After adjusting, apply touch-up paint (body color) onto the head of door hinge nuts.

JMKIA8084ZZ
