CAN DIAG SUPPORT MNTR

Refer to

LAN-12, "CAN Diagnostic Support Monitor"

.

MOTOR FAN

This test is able to check cooling fan operation [4/3/2/1].

EXTERNAL LAMPS

This test is able to check external lamp operation [Fog/Hi/Lo/TAIL/Off].

Test item

Description

WW-20

< ECU DIAGNOSIS INFORMATION >

BCM, IPDM E/R

ECU DIAGNOSIS INFORMATION

BCM, IPDM E/R

List of ECU Reference

INFOID:0000000009541143

ECU

Reference

BCM

BCS-28, "Reference Value"

BCS-44, "Fail-safe"

BCS-46, "DTC Inspection Priority Chart"

BCS-46, "DTC Index"

IPDM E/R

PCS-13, "Reference Value"

PCS-18, "Fail-safe"

PCS-20, "DTC Index"

FRONT WIPER AND WASHER SYSTEM

WW-21

< WIRING DIAGRAM >

C

D

E

F

G

H

I

J

K

M

A

B

WW

N

O

P

WIRING DIAGRAM

FRONT WIPER AND WASHER SYSTEM

Wiring Diagram

INFOID:0000000009541144

AALWA0632GB

WW-22

< WIRING DIAGRAM >

FRONT WIPER AND WASHER SYSTEM

AALIA1385GB
