Nissan Note E12. Manual - part 439

MA-4

< PREPARATION >

PREPARATION

PREPARATION

Special Service Tool

INFOID:0000000009417622

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Commercial Service Tool

INFOID:0000000009417623

Tool number
(Kent-Moore No.)
Tool name

Description

KV991J0070
(J-45695)
Coolant Refill Tool

Refilling engine cooling system

LMA053

Tool name

Description

Power tool

Loosening nuts, screws and bolts

KV10115801
(J-38956)
Oil filter wrench

Removing oil filter
a: 64.3 mm (2.531 in)

Spark plug wrench

Removing and installing spark plug
a: 14 mm (0.55 in)

Acoustic tension gauge

Checking drive belt tension

PIIB1407E

S-NT375

JPBIA0399ZZ

PBIC3881E

GENERAL MAINTENANCE

MA-5

< PERIODIC MAINTENANCE >

PERIODIC MAINTENANCE

GENERAL MAINTENANCE

General Maintenance

INFOID:0000000009452294

General maintenance includes those items which should be checked during the normal day-to-day operation

of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform the

checks and inspections themselves or they can have their NISSAN dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle,

etc.

Item

Reference page

Doors and engine hood

Check that all doors and the engine hood operate smoothly as well as the back door,
trunk lid and hatch. Also make sure that all latches lock securely. Lubricate if neces-
sary. Make sure that the secondary latch keeps the hood from opening when the pri-
mary latch is released. When driving in areas using road salt or other corrosive
materials, check lubrication frequently.

MA-42
MA-42
MA-43
MA-43

Lamps

Clean the headlamps on a regular basis. Make sure that the headlamps, stop lamps,
tail lamps, turn signal lamps, and other lamps are all operating properly and installed
securely. Also check the aim of the headlamps.

—

Tires

Check the pressure with a gauge often and always prior to long distance trips. Adjust
the pressure in all tires, including the spare, to the pressure specified. Check carefully
for damage, cuts or excessive wear.

WT-9

Tire rotation

In the case that Two-Wheel Drive (2WD) and front & rear tires are same size; Tires
should be rotated every 10,000 km (6,000 miles). Tires marked with directional indica-
tors can only be rotated between front and rear. Make sure that the directional indica-
tors point in the direction of wheel rotation after the tire rotation is completed.
In the case that Four-Wheel Drive (4WD) and front & rear tires are same size; Tires
should be rotated every 5,000 km (3,000 miles). Tires marked with directional indica-
tors can only be rotated between front and rear. Make sure that the directional indica-
tors point in the direction of wheel rotation after the tire rotation is completed.
In the case that front tires are different size from rear tires; Tires cannot be rotated.
However, the timing for tire rotation may vary according to your driving habits and the
road surface conditions.

WT-5

Tire Pressure Monitor-
ing System (TPMS)
transmitter components
(if equipped)

Replace the TPMS transmitter grommet seal, valve core and cap when the tires are
replaced due to wear or age.

—

Wheel alignment and
balance

If the vehicle should pull to either side while driving on a straight and level road, or if
you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If
the steering wheel or seat vibrates at normal highway speeds, wheel balancing may
be needed.

FSU-7
FSU-6
FSU-8

Windshield

Clean the windshield on a regular basis. Check the windshield at least every six
months for cracks or other damage. Repair as necessary.

—

Wiper blades

Check for cracks or wear if not functioning correctly.

—

Item

Reference page

Accelerator pedal

Check the pedal for smooth operation and make sure that the pedal does not catch or
require uneven effort. Keep the floor mats away from the pedal.

—

Brake pedal

Check the pedal for smooth operation and make sure that it attains the proper distance
from the floor mat when depressed fully. Check the brake booster function. Be sure to
keep the floor mats away from the pedal.

BR-15

Parking brake

Check the parking brake operation regularly. Check that the lever (if equipped) or the
pedal (if equipped) has the proper travel. Also make sure that the vehicle is held se-
curely on a fairly steep hill when only the parking brake is applied.

PB-4

MA-6

< PERIODIC MAINTENANCE >

GENERAL MAINTENANCE

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (for example, each time you check the engine oil or refuel.)

Seat belts

Check that all parts of the seat belt system (for example, buckles, anchors, adjusters
and retractors) operate properly and smoothly, and are installed securely. Check the
belt webbing for cuts, fraying, wear or damage.

MA-44

Steering wheel

Check for changes in the steering condition, such as excessive play, hard steering or
strange noises. Check that it has the specified play.
Free play: Less than 35 mm (1.38 in)

—

Warning lamps and
chimes

Make sure that all warning lamps and chimes are operating properly.

—

Windshield defogger

Check that the air comes out of the defogger outlets properly and in good quantity when
operating the heater or air conditioner.

—

Windshield wiper and
washer

Check that the wipers and washer operate properly and that the wipers do not streak.

—

Item

Reference page

Item

Reference page

Battery

Except for maintenance free battery; Check the fluid level in each cell. It should be be-
tween the “UPPER” and “LOWER” lines. Vehicles operated in high temperatures or un-
der severe conditions require frequent checks of the battery fluid level.

PG-60

Brake (and clutch) fluid
level(s)

For Manual Transmission (MT) model; Make sure that the brake and clutch fluid levels
are between the “MAX” and “MIN” lines on the reservoir(s).
Except for Manual Transmission (MT) model; Make sure that the brake fluid level is be-
tween the “MAX” and “MIN” lines on the reservoir.

MA-36
MA-30

Engine coolant level

Check the coolant level when the engine is cold. Make sure that the coolant level is be-
tween the “MAX” and “MIN” lines on the reservoir.

CO-8

Engine drive belt(s)

Make sure that drive belt(s) is/are not frayed, worn, cracked or oily.

EM-17

Engine oil level

Check the level after parking the vehicle (on a level ground) and turning off the engine.

LU-7

Fluid leaks

Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been
parked for a while. Water dripping from the air conditioner after use is normal. If you
should notice any leaks or if fuel fumes are evident, check for cause and have it cor-
rected immediately.

—

Windshield washer fluid Check that there is adequate fluid in the reservoir tank.

—

PERIODIC MAINTENANCE

MA-7

< PERIODIC MAINTENANCE >

PERIODIC MAINTENANCE

FOR MEXICO
FOR MEXICO : Periodic Maintenance

INFOID:0000000009452295

The following tables show the normal maintenance schedule. Depending upon weather and atmospheric con-

ditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent mainte-

nance may be required.

Periodic maintenance beyond the last period shown on the tables requires similar maintenance.

ENGINE AND EMISSION CONTROL MAINTENANCE (HR16DE ENGINE)

Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, E = Check and correct the engine coolant mixture ratio.

NOTE:

• Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving Condi-

tions”.

• (1) Periodic maintenance is not required. However, if valve noise increases, check valve clearance.
• (2) Replace the drive belts if found damaged.
• (3) Use Genuine NISSAN Engine Coolant (blue) or equivalent in its quality, in order to avoid possible aluminium corrosion within the

engine cooling system caused by the use of non-genuine engine coolant. Check and correct the engine coolant mixture ratio every
40,000 km (24,000 miles) or 24 months. First replacement interval is 160,000 km (96,000 miles) or 96 months. After first replacement,
replace every 80,000 km (48,000 miles) or 48 months.

• (4) Maintenance-free item.

CHASSIS AND BODY MAINTENANCE (HR16DE ENGINE)

Abbreviations: I = Inspect and correct or replace as necessary, R = Replace.

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Reference

page

Perform either at number of kilometers (miles)
or months, whichever comes first.

km x 1,000

(Miles x 1,000)

Months

(6)
