IDENTIFICATION INFORMATION

GI-33

< VEHICLE INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

GI

N

O

P

VEHICLE INFORMATION

IDENTIFICATION INFORMATION

Model Variation

INFOID:0000000009464398

Model Codes

Prefix and Suffix Designations

Body

Engine

Grade

Transmission

Destination

Mexico/LAM

Argentina

Hatchback

HR16DE

Base (Sense)

5 M/T

TDTALDF-EJA

TDTALDF-ELA

CVT

TDTALDZ-EJA

TDTALDZ-ELA

Mid (Advance)

5 M/T

TDTALEF-EJA

TDTALEF-ELA

CVT

TDTALEZ-EJA

TDTALEZ-ELA

Position

Character

Qualifier

Definition

1

T

Body type

T: Hatchback

2

DT

Engine

DT: HR16DE

3

4

A

Axle

A: 2WD

5

L

Drive

L:  LH

6

D

Grade

D: Base (Sense)

E: Mid (Advance)

7

F

Transmission

F: 5 M/T

Z: CVT

8

E12

Model

E12: Note

9

10

11

E

Intake

E: EGI

12

J

Zone

J: Mexico/LAM

L: Argentina

13

A

Equipment

A: Standard

14

XXXXX

Option Codes

Option Codes

15

16

17

18

GI-34

< VEHICLE INFORMATION >

IDENTIFICATION INFORMATION

Identification Number

INFOID:0000000009464399

Vehicle Identification Number Arrangement

1. Air conditioner specification label

2. Vehicle identification number chas-

sis number (right side of bulkhead)

3. Emission control information label (if

equipped)

4. Tire placard

ALAIA0093ZZ

Position

Character

Qualifier

Definition

1

3N1

Manufacturer

3N1: NISSAN Passenger Car [Nismex]

2

3

4

C

Engine type

C: HR16DE

5

E2

Model series

E2: NISSAN Note model code E12

6

7

C

Body type

C: 4 door hatchback

8

D

Restraint system

D: Driver and Passenger Air Bags and 3-point manual seat belts

9

*

Check digit

(0 to 9 or X) The code for the check digit is determined by a mathematical computation

10

E

Model year

E: 2014

Z: General exportation

11

L

Manufacturing plant

L: Aguascalientes, Mexico

K: Civac, Mexico

IDENTIFICATION INFORMATION

GI-35

< VEHICLE INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

GI

N

O

P

Engine Serial Number

INFOID:0000000009464400

HR16DE

: Vehicle front

CVT Number

INFOID:0000000009464401

Manual Transaxle Number

INFOID:0000000009464402

: Vehicle front

12

XXXXXX

Vehicle serial number Chassis number

13

14

15

16

17

Position

Character

Qualifier

Definition

STI0429

LAIA0074E

PCIB1612E

GI-36

< VEHICLE INFORMATION >

IDENTIFICATION INFORMATION

Dimensions

INFOID:0000000009464403

Unit:mm (in)

Wheels & Tires

INFOID:0000000009464404

Overall length

4,141 (163)

Overall width

1,645 (64.8)

Overall height

1,537 (60.5)

Front tread

15 inch wheel: 1,480 (58.3)
16 inch wheel: 1,470 (57.9)

Rear tread

15 inch wheel: 1,485 (58.5)
16 inch wheel: 1,475 (58.1)

Wheelbase

2,600 (102.4)

Conventional

Spare

Road wheel/offset mm (in)

15 X 5.5J Aluminum/40 (1.57)
16 X 6.0J Aluminum/45 (1.77)

T125/70D15

Tire size

P185/65R15
P195/55R16
