MWI
COMBINATION METER
MWI-31
< ECU DIAGNOSIS INFORMATION >
C
D
E
F
G
H
I
J
K
L
M
B
A
O
P
DTC Index
INFOID:0000000011279791
Warning lamp/indicator lamp
ABS warning lamp
Turns ON by suspending communication.
Brake warning lamp
EPS warning lamp
VDC warning lamp
AWD warning lamp
Malfunction indicator lamp
Airbag warning lamp
Charge warning lamp
VDC OFF indicator lamp
Turns OFF by suspending communication.
SPORT mode indicator lamp
AWD LOCK indicator lamp
High beam indicator lamp
Turn signal indicator lamp
Position lamp indicator lamp
OD OFF indicator lamp
BSW indicator lamp
LDW indicator lamp
ECO mode indicator lamp
Front fog lamp indicator lamp
Hill descent control indicator lamp
Low tire pressure warning lamp
After blinking for 1 minute, the lamp remains ON.
Function
Specifications
Display contents of CONSULT
Diagnostic item is detected when...
Refer to
CAN COMM CIRCUIT
[U1000]
Combination meter is not transmitting or receiving CAN communication signal for 2
seconds or more.
CONTROL UNIT (CAN)
[U1010]
Detecting error during the initial diagnosis of CAN controller of combination meter.
VEHICLE SPEED
[B2205]
The abnormal vehicle speed signal is input from ABS actuator and electric unit (con-
trol unit) for 2 seconds or more.
ENGINE SPEED
[B2267]
ECM continuously transmits abnormal engine speed signals for 2 seconds or more.
WATER TEMP
[B2268]
ECM continuously transmits abnormal engine coolant temperature signals for 60
seconds or more.
