DLK-250 < REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM] FRONT DOOR DOOR HINGE INFOID:0000000011279008 REMOVAL 1. Remove front fender. Refer to DLK-245, "Removal and Installation" 2. Remove front door assembly. Refer to DLK-247, "DOOR ASSEMBLY : Removal and Installation" . 3. Remove front door hinge bolts (body side) and front door hinge. INSTALLATION Installation is in the reverse order of removal. CAUTION: • Tighten nuts/bolts to specified torque. Refer to • Apply anticorrosive agent to the hinge mating surface. • After installation, check front door open/close and lock/unlock operation. • Check door hinge rotating point for poor lubrication. If necessary, apply a suitable multi-purpose grease. • After installation, perform the front door adjustment procedure. Refer to DOOR CHECK LINK INFOID:0000000011279009 REMOVAL 1. Fully close the front door window. AV-70, "Removal and Installation" (DISPLAY AUDIO), (NAVIGATION WITHOUT BOSE) or AV-374, "Removal and Installation" (NAV- IGATION WITH BOSE). 3. Remove door check link bolt (body side). INSTALLATION Installation is in the reverse order of removal. CAUTION: • Tighten nuts/bolts to specified torque. Refer to • After installation, check front door open/close and lock/unlock operation. • Check door check link rotating point for poor lubrication. If necessary, apply a suitable multi-pur- pose grease. 2015 Rogue NAM |
