RF-52

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

DTC Index

INFOID:0000000004496864

NOTE:

Details of time display

4

• B2013: ID DISCORD BCM-S/L
• B2014: CHAIN OF S/L-BCM
• B2553: IGNITION RELAY
• B2555: STOP LAMP
• B2556: PUSH-BTN IGN SW
• B2557: VEHICLE SPEED
• B2601: SHIFT POSITION
• B2602: SHIFT POSITION
• B2603: SHIFT POSI STATUS
• B2604: PNP SW
• B2605: PNP SW
• B2606: S/L RELAY
• B2607: S/L RELAY
• B2609: S/L STATUS
• B260A: IGNITION RELAY
• B260B: STEERING LOCK UNIT
• B260C: STEERING LOCK UNIT
• B260D: STEERING LOCK UNIT
• B260F: ENG STATE SIG LOST
• B2611: ACC RELAY
• B2612: S/L STATUS
• B2614: ACC RELAY CIRC
• B2615: BLOWER RELAY CIRC
• B2616: IGN RELAY CIRC
• B2617: STARTER RELAY CIRC
• B2618: BCM
• B2619: BCM
• B261A: PUSH-BTN IGN SW
• B26E1: ENG STATE NO RECIV
• C1729: VHCL SPEED SIG ERR
• U0415: VEHICLE SPEED SIG

5

• C1704: LOW PRESSURE FL
• C1705: LOW PRESSURE FR
• C1706: LOW PRESSURE RR
• C1707: LOW PRESSURE RL
• C1708: [NO DATA] FL
• C1709: [NO DATA] FR
• C1710: [NO DATA] RR
• C1711: [NO DATA] RL
• C1712: [CHECKSUM ERR] FL
• C1713: [CHECKSUM ERR] FR
• C1714: [CHECKSUM ERR] RR
• C1715: [CHECKSUM ERR] RL
• C1716: [PRESSDATA ERR] FL
• C1717: [PRESSDATA ERR] FR
• C1718: [PRESSDATA ERR] RR
• C1719: [PRESSDATA ERR] RL
• C1720: [CODE ERR] FL
• C1721: [CODE ERR] FR
• C1722: [CODE ERR] RR
• C1723: [CODE ERR] RL
• C1724: [BATT VOLT LOW] FL
• C1725: [BATT VOLT LOW] FR
• C1726: [BATT VOLT LOW] RR
• C1727: [BATT VOLT LOW] RL
• C1734: CONTROL UNIT

6

• B2621: INSIDE ANTENNA
• B2622: INSIDE ANTENNA
• B2623: INSIDE ANTENNA

Priority

DTC

BCM (BODY CONTROL MODULE)

RF-53

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

• CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning igni-

tion switch OFF

→ ON again.

• 1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases like 1

→ 2 → 3...38 → 39 after returning to the normal condition whenever ignition switch OFF → ON. The counter

remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch

OFF

→ ON after returning to the normal condition if the malfunction is detected again.

CONSULT display

Fail-safe

Intelligent Key

warning lamp ON

Tire pressure

monitor warning

lamp ON

Reference page

No DTC is detected.
further testing
may be required.

—

—

—

—

U1000: CAN COMM CIRCUIT

—

—

—

U1010: CONTROL UNIT (CAN)

—

—

—

U0415: VEHICLE SPEED SIG

—

—

—

B2013: ID DISCORD BCM-S/L

×

—

—

B2014: CHAIN OF S/L-BCM

×

—

—

B2190: NATS ANTENNA AMP

×

—

—

B2191: DIFFERENCE OF KEY

×

—

—

B2192: ID DISCORD BCM-ECM

×

—

—

B2193: CHAIN OF BCM-ECM

×

—

—

B2553: IGNITION RELAY

—

—

—

B2555: STOP LAMP

—

—

—

B2556: PUSH-BTN IGN SW

—

×

—

B2557: VEHICLE SPEED

×

×

—

B2562: LOW VOLTAGE

—

—

—

B2563: HI VOLTAGE

×

×

—

B2601: SHIFT POSITION

×

×

—

B2602: SHIFT POSITION

×

×

—

B2603: SHIFT POSI STATUS

×

×

—

B2604: PNP SW

×

×

—

B2607: S/L RELAY

×

×

—

B2609: S/L STATUS

×

×

—

B260A: IGNITION RELAY

×

×

—

B260B: STEERING LOCK UNIT

—

×

—

B260C: STEERING LOCK UNIT

—

×

—

B260D: STEERING LOCK UNIT

—

×

—

B260F: ENG STATE SIG LOST

×

×

—

B2611: ACC RELAY

—

—

—

B2612: S/L STATUS

×

×

—

B2614: ACC RELAY CIRC

—

×

—

B2615: BLOWER RELAY CIRC

—

×

—

B2616: IGN RELAY CIRC

—

×

—

B2617: STARTER RELAY CIRC

×

×

—

B2618: BCM

×

×

—

B2619: BCM

×

×

—

B261A: PUSH-BTN IGN SW

—

×

—

RF-54

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

B261E: VEHICLE TYPE

×

× (Turn ON for 15

seconds)

—

B2621: INSIDE ANTENNA

—

—

—

B2622: INSIDE ANTENNA

—

—

—

B2623: INSIDE ANTENNA

—

—

—

C1704: LOW PRESSURE FL

—

—

×

C1705: LOW PRESSURE FR

—

—

×

C1706: LOW PRESSURE RR

—

—

×

C1707: LOW PRESSURE RL

—

—

×

C1708: [NO DATA] FL

—

—

×

C1709: [NO DATA] FR

—

—

×

C1710: [NO DATA] RR

—

—

×

C1711: [NO DATA] RL

—

—

×

C1712: [CHECKSUM ERR] FL

—

—

×

C1713: [CHECKSUM ERR] FR

—

—

×

C1714: [CHECKSUM ERR] RR

—

—

×

C1715: [CHECKSUM ERR] RL

—

—

×

C1716: [PRESSDATA ERR] FL

—

—

×

C1717: [PRESSDATA ERR] FR

—

—

×

C1718: [PRESSDATA ERR] RR

—

—

×

C1719: [PRESSDATA ERR] RL

—

—

×

C1720: [CODE ERR] FL

—

—

×

C1721: [CODE ERR] FR

—

—

×

C1722: [CODE ERR] RR

—

—

×

C1723: [CODE ERR] RL

—

—

×

C1724: [BATT VOLT LOW] FL

—

—

×

C1725: [BATT VOLT LOW] FR

—

—

×

C1726: [BATT VOLT LOW] RR

—

—

×

C1727: [BATT VOLT LOW] RL

—

—

×

C1729: VHCL SPEED SIG ERR

—

—

×

C1734: CONTROL UNIT

—

—

×

CONSULT display

Fail-safe

Intelligent Key

warning lamp ON

Tire pressure

monitor warning

lamp ON

Reference page

SUNROOF MOTOR ASSEMBLY

RF-55

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

SUNROOF MOTOR ASSEMBLY

Reference Value

INFOID:0000000004216174

TERMINAL LAYOUT

PHYSICAL VALUES

WIIA1344E

Terminal No.

(Wire color)

Description

Condition

Voltage (V)

(Approx.)

+

-

Signal name

Input/

Output

1

(G)

Ground

Sunroof close switch (BIT
1) signal

Input

Sunroof switch in following posi-
tion
• TILT UP
• SLIDE CLOSE

0

Other than above

Battery voltage

2

(B)

Ground

Ground

—

—

0

5

(Y)

Ground

Sunroof open switch (BIT
0) signal

Input

Sunroof switch in following posi-
tion
• TILT DOWN
• SLIDE OPEN

0

Other than above

Battery voltage

7

(R/Y)

Ground

Sunroof power supply

Input

—

Battery voltage

8

(L/B)

Ground

Vehicle speed signal (2-
pulse)

Input

Speedometer operated [When
vehicle speed is approx.40km/ h
(25MPH)]

9

(L/W)

Ground

RAP signal

Input

Ignition switch ON

Battery voltage

Within 45 second after ignition
switch is turned to OFF.

Battery voltage

When driver side or passenger
side door is opened during re-
tained power operation.

0

10

(R)

Ground

Ground

—

—

0

ELF1080D
