PG HARNESS CONNECTOR PG-59 < COMPONENT DIAGNOSIS > C D E F G H I J K L B A O P N HARNESS CONNECTOR Description INFOID:0000000004497107 HARNESS CONNECTOR (TAB-LOCKING TYPE) • The tab-locking type connectors help prevent accidental looseness or disconnection. • The tab-locking type connectors are disconnected by pushing or lifting the locking tab(s). Refer to the figure below. Refer to the next page for description of the slide-locking type connector. CAUTION: Do not pull the harness or wires when disconnecting the connector. [Example] HARNESS CONNECTOR (SLIDE-LOCKING TYPE) • A new style slide-locking type connector is used on certain systems and components, especially those related to OBD. • The slide-locking type connectors help prevent incomplete locking and accidental looseness or disconnec- tion. SEL769DA |
