PG POWER SUPPLY ROUTING CIRCUIT PG-23 < COMPONENT DIAGNOSIS > C D E F G H I J K L B A O P N Fuse INFOID:0000000004219223 • If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. • Use fuse of specified rating. Never use fuse of more than specified rating. • Do not partially install fuse; always insert it into fuse holder prop- erly. • Remove fuse for “ELECTRICAL PARTS (BAT)” if vehicle is not used for a long period of time. Fusible Link INFOID:0000000004219224 A melted fusible link can be detected either by visual inspection or by feeling with finger tip. If its condition is questionable, use circuit tester or test lamp. CAUTION: • If fusible link should melt, it is possible that critical circuit (power supply or large current carrying circuit) is shorted. In such a case, carefully check and eliminate cause of malfunc- tion. • Never wrap outside of fusible link with vinyl tape. Important: Never let fusible link touch any other wiring harness, vinyl or rubber parts. CEL083 1 : Fusible link ALMIA0159GB |
