EC-288 < COMPONENT DIAGNOSIS > [QR25DE] P0452 EVAP CONTROL SYSTEM PRESSURE SENSOR P0452 EVAP CONTROL SYSTEM PRESSURE SENSOR Description INFOID:0000000004363286 The EVAP control system pressure sensor detects pressure in the purge line. The sensor output voltage to the ECM increases as pres- sure increases. DTC Logic INFOID:0000000004211522 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1. PRECONDITIONING If DTC Confirmation Procedure has been previously conducted, always perform the following before conduct- ing the next test. 1. Turn ignition switch OFF and wait at least 10 seconds. 2. Turn ignition switch ON. 3. Turn ignition switch OFF and wait at least 10 seconds. TESTING CONDITION: Always perform test at a temperature of 5 °C (41°F) or more. >> GO TO 2. 2. PERFORM DTC CONFIRMATION PROCEDURE With CONSULT-III 1. Activate “INSPECTION MODE 1” ( ) to start engine, and warm up engine to normal operating temperature. 2. Turn ignition switch OFF and wait at least 10 seconds. 3. Turn ignition switch ON. 4. Select “DATA MONITOR” mode with CONSULT-III. 5. Make sure that “FUEL T/TMP SE” is more than 0 °C (32°F). 6. Activate “INSPECTION MODE 1” ( ) to start engine, and wait at least 20 seconds. 7. Check 1st trip DTC. With GST 1. Activate “INSPECTION MODE 1” ( ) to start engine, and warm up engine to normal operating temperature. PBIB3370E DTC No. Trouble diagnosis name DTC detecting condition Possible cause P0452 EVAP control system An excessively low voltage from the sensor is • Harness or connectors (EVAP control system pressure sensor • EVAP control system pressure sensor |
