Nissan Frontier. Manual - part 1110





RSU-12

< SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

General Specification (Rear)

INFOID:0000000009478700

Wheelarch Height (Unladen*

1

)

INFOID:0000000009478701

King Cab

Unit: mm (in)

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.

Crew Cab

Unit: mm (in)

Suspension type

Rigid axle with semi-elliptic leaf springs

Shock absorber type

Double-acting hydraulic

Drive type

2WD

4WD

Engine type

QR25DE

VQ40DE

Tire size

P235/75R15

P265/70R16

P265/70R16

P265/75R16

P265/70R16

P265/75R16

Front wheelarch height (Hf)

850

(33.46)

865

(34.06)

868

(34.17)

880

(34.65)

881

(34.68)

893

(35.16)

Rear wheelarch height (Hr)

878

(34.57)

887

(34.92)

895

(35.24)

907

(35.71)

904

(35.59)

917

(36.10)

LEIA0085E

Engine type

VQ40DE

Drive type

2WD

4WD

Tire size

P265/70R16

P265/75R16

P265/60R18

P265/70R16

P265/75R16

P265/60R18

Wheel base

Short

Long

Short

Short

Long

Short

Long

Short

Short

Long

LEIA0085E

SERVICE DATA AND SPECIFICATIONS (SDS)

RSU-13

< SERVICE DATA AND SPECIFICATIONS (SDS)

C

D

F

G

H

I

J

K

L

M

A

B

RSU

N

O

P

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.

Front
wheelarch
height (Hf)

867

(34.13)

870

(34.25)

879

(34.61)

866

(34.09)

869

(34.21)

879

(34.61)

882

(34.72)

891

(35.08)

879

(34.61)

882

(34.72)

Rear
wheelarch
height (Hr)

892

(35.12)

892

(35.12)

904

(35.59)

892

(35.12)

892

(35.12)

905

(35.63)

902

(35.51)

918

(36.14)

905

(35.63)

902

(35.51)

SB-2

< PRECAUTION >

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000010150617

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS

system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front

air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SR and SB section of this Service Man-

ual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by

an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag

Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-

ness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-

tion ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a

hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing

serious injury.

• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the

battery and wait at least three minutes before performing any service.

Precaution for Seat Belt Service

INFOID:0000000009482270

CAUTION:

• Before removing the seat belt pre-tensioner assembly, turn the ignition switch OFF, disconnect both

battery cables and wait at least 3 minutes.

• After replacing or reinstalling seat belt pre-tensioner assembly, or reconnecting seat belt pre-ten-

sioner assembly connector, ensure entire SRS operates properly. Refer to

SRC-13, "SRS Operation

Check"

.

• Do not disassemble buckle or seat belt assembly.

• Do not reuse seat belt anchor bolts after removal. Replace with new ones.

• Replace anchor bolts if they are deformed or worn out.

• Do not oil tongue and buckle.

• If any component of seat belt assembly is questionable, do not repair. Replace the whole seat belt

assembly.

• If webbing is cut, frayed, or damaged, replace seat belt assembly.

• When replacing seat belt assembly, use a genuine NISSAN seat belt assembly.
