Nissan Sentra. Manual - part 134

BCS-106

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

BCM

(GR)

Ground Key sw signal

Input

Ignition switch

Ignition key inserted into
ignition key cylinder

Battery voltage

Ignition key removed from
ignition key cylinder

0 V

(R)

Ground Ign sw signal

Input

Ignition switch

OFF or ACC

0 V

ON or START

Battery voltage

(L)

Ground CAN-H signal

Input/

Output

—

(P)

Ground CAN-L signal

Input/

Output

—

(LG)

Ground

Flasher output
(LEFT) signal

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch LH

6.5 V

(Turn signal lamp turn on: 9 - 16

(O)

Ground

Flasher output
(RIGHT) signal

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch RH

6.5 V

(Turn signal lamp turn on: 9 - 16

(R)

Ground Door sw (AS) signal

Input

Front door
switch RH

OFF (front door RH
closed)

7.0 - 8.0 V

ON (front door RH open)

0 V

(Y)

Ground Door sw (DR) signal

Input

Front door
switch LH

OFF (front door LH
closed)

7.0 - 8.0 V

ON (front door LH open)

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

−

PKIC6370E

PKIB4960J

BCS

BCM

BCS-107

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

(GR)

Ground Door sw (RL) signal

Input

Rear door
switch LH

OFF (rear door LH closed)

7.0 - 8.0 V

ON (rear door LH open)

0 V

(P)

Ground Door sw (RR) signal

Input

Rear door
switch RH

OFF (rear door RH
closed)

7.0 - 8.0 V

ON (rear door RH open)

0 V

(LG)

Ground

Luggage lamp out-
put signal

Output

Trunk lid

Closed (trunk room lamp
OFF)

Battery voltage

Open (trunk room lamp
ON)

0 – 1 V

(V)

Ground

Tr room lamp sw sig-
nal

Input

Trunk lid switch

OFF
(Trunk lid closed)

7.0 - 8.0 V

ON (Trunk lid open)

0 V

(GR)

Ground Trunk open output

Output

Trunk opener
request switch
released

Trunk lid actuator idle

0 V

Trunk opener
request switch
depressed

Trunk lid actuator activat-
ed

Battery voltage

(BR)

Ground

Room lamp output
signal

Output

Interior room
lamp or map
lamp

OFF

Battery voltage

DOOR

0 – 1 V

(P)

Ground

Battery saver output
signal

Output

Interior room lamp battery saver activated

0 V

Interior room lamp battery saver not activat-
ed

Battery voltage

(O)

Ground Battery (FUSE)

Input

Ignition switch OFF

Battery voltage

(SB)

Ground

Door unlock output
(DR) signal

Output

Front door lock
actuator LH

Actuated to UNLOCK po-
sition

Battery voltage

Other than actuated to
UNLOCK position

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

−

PKIB4960J

BCS-108

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

BCM

Fail-safe

INFOID:0000000009757382

FAIL-SAFE CONTROL BY DTC

BCM performs fail-safe control when any DTC are detected.

FAIL-SAFE CONTROL OF COMBINATION SWITCH READING FUNCTION CAUSED BY LOW
POWER SUPPLY VOLTAGE

If voltage of battery power supply lower, BCM maintains combination switch reading to the status when input

voltage is less than approximately 9 V.

NOTE:

When voltage of battery power supply is approximately 9 V or more, combination switch reading function

returns to normal operation.

DTC Inspection Priority Chart

INFOID:0000000009757383

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority

chart.

(B)

Ground Gnd

Output

Ignition switch ON

0 V

(O)

Ground

Door lock output sig-
nal

Output

All door lock ac-
tuators

Actuated to LOCK posi-
tion

Battery voltage

Other than actuated to
LOCK position

0 V

(SB)

Ground

Door unlock output
(AS, RR, RL) signal

Output

Front door lock
actuator RH,
rear door lock
actuator RH and
rear door lock
actuator LH

Actuated to UNLOCK po-
sition

Battery voltage

Other than actuated to
UNLOCK position

0 V

(L)

Ground

Power window pow-
er supply (RAP) sig-
nal

Output

Ignition switch ON

Battery voltage

(G)

Ground

Power window pow-
er supply (BATT)

Output

Push-button ig-
nition switch

OFF

Battery voltage

(Y)

Ground Battery (F/L)

Input

Ignition switch OFF

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

−

Display contents of CONSULT

Fail-safe

Cancellation

B2190: NATS ANTENNA AMP

Inhibit engine cranking

Erase DTC

B2191: DIFFERENCE OF KEY

Inhibit engine cranking

Erase DTC

B2192: ID DISCORD BCM-ECM

Inhibit engine cranking

Erase DTC

B2193: CHAIN OF BCM-ECM

Inhibit engine cranking

Erase DTC

B2195: ANTI SCANNING

Inhibit engine cranking

Ignition switch ON

→ OFF

B2196: DONGLE NG

Inhibit engine cranking

Erase DTC

BCS

BCM

BCS-109

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

DTC Index

INFOID:0000000009757384

NOTE:

Details of time display

• CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning igni-

tion switch OFF

→ ON again.

• 1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases like 1

→ 2 → 3...38 → 39 after returning to the normal condition whenever ignition switch OFF → ON. The counter

remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch

OFF

→ ON after returning to the normal condition if the malfunction is detected again.

Priority

DTC

• U1000: CAN COMM
• U1010: CONTROL UNIT (CAN)

• B2190: NATS ANTENNA AMP
• B2191: DIFFERENCE OF KEY
• B2192: ID DISCORD BCM-ECM
• B2193: CHAIN OF BCM-ECM
• B2195: ANTI SCANNING
• B2196: DONGLE NG

• C1704: LOW PRESSURE FL
• C1705: LOW PRESSURE FR
• C1706: LOW PRESSURE RR
• C1707: LOW PRESSURE RL
• C1708: [NO DATA] FL
• C1709: [NO DATA] FR
• C1710: [NO DATA] RR
• C1711: [NO DATA] RL
• C1716: [PRESS DATA ERR] FL
• C1717: [PRESS DATA ERR] FR
• C1718: [PRESS DATA ERR] RR
• C1719: [PRESS DATA ERR] RL
• C1729: VHCL SPEED SIG ERR

CONSULT display

Fail-safe

Low tire pressure
warning lamp ON

Reference

U1000: CAN COMM

—

BCS-118

U1010: CONTROL UNIT (CAN)

—

BCS-119

B2190: NATS ANTENNA AMP

—
