AV-308

< REMOVAL AND INSTALLATION >

[NAVIGATION WITHOUT BOSE]

WINDOW ANTENNA

WINDOW ANTENNA

Removal and Installation

INFOID:0000000010304574

The window antenna is serviced as an assembly with the filament. Refer to

DEF-47, "Inspection and Repair"

.

AV

SATELLITE RADIO ANTENNA

AV-309

< REMOVAL AND INSTALLATION >

[NAVIGATION WITHOUT BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

SATELLITE RADIO ANTENNA

Removal and Installation

INFOID:0000000009758996

REMOVAL

1. Lower the headlining at the rear. Refer to

INT-38, "Exploded View"

.

2. Remove the satellite radio antenna nut (A).
3. Disconnect the harness connector (B) from the satellite radio

antenna (1) and remove.

INSTALLATION

Installation is in the reverse order of removal.

ALNIA1412ZZ

AV-310

< REMOVAL AND INSTALLATION >

[NAVIGATION WITHOUT BOSE]

GPS ANTENNA

GPS ANTENNA

Removal and Installation

INFOID:0000000009758997

REMOVAL

1. Remove the combination meter. Refer to

MWI-77, "Removal and Installation"

.

2. Remove the AV control unit. Refer to

AV-298, "Removal and Installation"

.

3. Remove the screw (A) from the GPS antenna (1).

4. Release the harness clips (A) from the instrument panel (1) and

remove the GPS antenna.

INSTALLATION

Installation is in the reverse order of removal.

ALNIA1413ZZ

AWNIA2817ZZ

AV

MICROPHONE

AV-311

< REMOVAL AND INSTALLATION >

[NAVIGATION WITHOUT BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

MICROPHONE

Removal and Installation

INFOID:0000000009758998

REMOVAL

1. Remove the front room/map lamp assembly. Refer to

INL-52, "Removal and Installation"

.

2. Disconnect the microphone connector (A) from the front room/

map lamp assembly (2).

3. Release the microphone pawls, then remove the microphone

(1).

: Pawl

INSTALLATION

Installation is in the reverse order of removal.

ALNIA1366ZZ
