REAR COMBINATION LAMP EXL-141 < REMOVAL AND INSTALLATION > [LED HEADLAMP] C D E F G H I J K M A B EXL N O P • Fogging of rear combination lamp inside is not a malfunction. Never replace parts. Fogging is a symptom in which inner surface of lens becomes whitely clouded, without there being visible water drops or water spots, as if lens is made of frosted-glass. REMOVAL 1. Remove luggage side lower finisher. Refer to INT-43, "LUGGAGE SIDE LOWER FINISHER : Removal 2. Disconnect rear combination lamp connector. apply protective tape. CAUTION: • To prevent rear fender panel paint surface from being damaged, always apply protection using a shop cloth or protective tape. • When using protective tape, apply protective tape to both rear fender panel and rear combination lamp. 5. Pull rear combination lamp toward vehicle rear side, as shown by the arrow in the figure. 6. Remove rear combination lamp. INSTALLATION Note the following item, and then install in the reverse order of removal. CAUTION: JMLIA2386ZZ : Clip JMLIA2385ZZ |
