• Based on the data stored at the Nissan CARWINGS Data Center, ECO drive history, advice, ECO rank, etc.

are displayed and checked with probe information.

AV-520

< SYSTEM DESCRIPTION >

[TELEMATICS SYSTEM]

OPERATION

OPERATION

Switch Name and Function

INFOID:0000000010122735

Names and functions of AV control unit switches

1. Design

2. Switch name and function

No.

Switch name

Function

1

FM·AM

Press to switch between the FM radio band and the AM radio band.

2

XM

Press to switch to an XM satellite radio band.

3

CD·AUX

Press to switch between USB memory/iPod player

*1

/CD/Bluetooth

®

 streaming audio

*2

 /

AUX screens.

4

VOL (volume control)

Press to adjust the volume of the stereo.

5

 (audio system ON·OFF)

Press to turn the audio system ON or OFF.

6

 (Day/Night)

• Press to switch between the day screen (bright) and the night screen (dark).
• Press and hold to turn OFF the display, then press again to turn ON the display.

7

CAMERA

Press to turn the around view monitor system ON or OFF.

8

OPEN/TILT

• Press to open the monitor to access the CD slot and the SD card slot.
• Press and hold to adjust the monitor angle (6 angles).

9

 (Zero emission)

Press to display the setting screen where several useful functions for electric vehicle driv-
ing are determined.

10

TUNE/SEEK/CH

• Press to select a track/station.
• Press and hold to search for a track/station automatically or to fast-forward/back-forward

when listening to music.

11

STATUS

Press to display the current status of the air conditioner, radio, audio, vehicle information
(estimated distance, drivable distance and average energy economy) and navigation sys-
tems.

12

MENU

Press to display the setting menu (destination, route, information, settings, phone and car-
wings) screen.

AWNIA3021ZZ

AV

OPERATION

AV-521

< SYSTEM DESCRIPTION >

[TELEMATICS SYSTEM]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

• *1: Displayed when iPod

®

 is connected.

• *2: Displayed when Bluetooth

®

audio is registered and “Bluetooth connection” setting is ON.

Menu Display by Pressing Each Switch

INFOID:0000000010122736

NOTE:

For Navigation system and Telematics system operation detailed information, refer to Navigation system

Owner's Manual.

MENU

When the MENU switch is pressed, the menu screen is displayed.

13

MAP/VOICE

• Press to display the current location map screen.
• Press and hold to repeat voice guidance.

14

 (Disk eject)

Press to eject a disk.

No.

Switch name

Function

AVA1281

Menu list

Description

Destination

Change Country

When setting a destination, the country can be selected. The country that is last selected is
automatically selected by the system as the default.

New Address

Searches for a destination by address.

Home

Searches for a route from the current location to the previously stored home destination.

Points of interest Searches for a destination from various categories of businesses or locations.

Charging Station Searches for the charging stations near the current vehicle location.

Quick Stop

Searches for points of interest near the current vehicle location, such as restaurants, charging
stations, etc.

Address Book

Searches for a destination from the list of the stored locations.

History

• Sets the previous starting point as destination.
• Searches for the destination from the previous destinations.

M-way En-
trance/Exit

Searches for a destination from a motorway entrance/exit.

Stored Routes

Selects a stored route.

Latitude/Longi-
tude

Searches for a destination by entering the latitude and the longitude.

Junction

Searches for a destination from junctions.

AV-522

< SYSTEM DESCRIPTION >

[TELEMATICS SYSTEM]

OPERATION

Route

Cancel Route/
Resume Route

Cancels the current route guidance. A cancelled route can also be reactivated. If the suggest-
ed route is cancelled, “Cancel Route” changes to “Resume Route”.

Edit Route

Edit or add a destination or waypoints to the route that is already set.

Route Info

Confirm the route by the route information or simulation. The confirmed route can also be
stored.

Guidance Voice

Activates or deactivates route, voice guidance and/or traffic announcement and adjust the vol-
ume level of voice guidance.

Recalculate

Manually search for the route again after changing the search condition and have the system
calculate a route.

Detour

A detour of a specified distance can be calculated.

Traffic Detour

Manually search for an alternative detour route taking the traffic information into consideration.

Route Calcula-
tion Criteria

Changes the route calculation conditions anywhere along the route.

Information

Traffic Informa-
tion

Displays the Traffic Information.

Energy Info.

Energy information is displayed on the screen.

Maintenance

Displays the vehicle maintenance information.

Charging Station
Info

Displays charging station information for the current location.

Where am I?

Displays information regarding the current vehicle location.

Voice Recogni-
tion

Displays the voice command list.

GPS Position

Displays GPS information regarding the current vehicle location.

Navigation Ver-
sion

Displays the current navigation system version.

Settings

The following system items can be customized.

Phone

Phonebook

Select a telephone number from the phone book, and then make a call. Before making a call,
the telephone number must be registered in the phone book.

Call History

Select a telephone number from the incoming or outgoing history lists, and then make a call.

Handset Memo-
ry

Download the phone book from a cellular phone that is connected to the vehicle, select a tele-
phone number from the phone book, and then make a call. Phone book data should be regis-
tered in the system after downloading the phone book from the cellular phone that is
connected to the vehicle. If the phone book is not registered, a message that reminds of phone
book data download is displayed.

Keypad

Input the phone number manually using the keypad displayed on the screen.

Volume

Adjust various settings of phone volume.

Pair Phone

• When a PIN code appears on the screen, operate the compatible Bluetooth

®

 cellular phone

to enter the PIN code.

•  When the connection process is completed, the screen will returns to the Phone menu dis-

play.

Paired Phone

The list of the registered cellular phones is displayed.

CARWINGS

Favorite Chan-
nels

A maximum of 16 favorite channels selected from the information channels can be stored in
a folder.

Information
Channels

Touch the preferred folder. An information channel list is displayed.

CARWINGS
Records

The information channels that are referred to previously are displayed. A maximum of 3 chan-
nels are stored in the history.

Update Stations

Charging station information is updated through connection to the Nissan CARWINGS Data
Center.

CARWINGS
Settings

The CARWINGS system can be customized.
