Power door lock/unlock operation by lock knob ● With lock knob on driver or passenger door setting to LOCK while all doors are closed will lock all doors. ● With lock knob on driver or passenger door setting to UNLOCK while all doors are closed will unlock all Lock knob operation cannot control super lock. Key reminder system ● If the ignition key is in the ignition key cylinder and any door is open, setting the lock/unlock switch or Central unlock/trunk or back door release switch Signal input Status Short press Long press DR AS RL RR Without ultra sonic With ultra sonic Without ultra sonic With ultra sonic No action No action Trunk release Trunk release U U U U Fully No action No action Trunk release Trunk release U U U L No action No action Trunk release Trunk release U U L U No action Central unlock Trunk release Central unlock U U L L DR and AS Central unlock Central unlock Central unlock Central unlock U L X X DR door Central unlock Central unlock Central unlock + Central unlock + L L X X Both front No action No action No action No action L L L L Super locked U: Unlocked; L: locked; X: Don’t care System initialisation ● System initialisation is required when battery cables are reconnected. Conduct one of the followings to POWER DOOR LOCK — Super Lock — System Description/Super Lock for RHD EL-267 |
