DTC P0461 FUEL LEVEL SENSOR EC-1563 [VG33ER] C D E F G H I J K L M A EC WITH GST NOTE: Prepare a fuel container and a spare hose. 2. Release fuel pressure from fuel line, refer to EC-1218, "FUEL PRESSURE RELEASE" 3. Remove the fuel feed hose on the fuel level sensor unit. 4. Connect a spare fuel hose where the fuel feed hose was removed. 5. Turn ignition switch OFF. 6. Set voltmeters probe between ECM terminal 46 (fuel level sen- 7. Turn ignition switch ON. 8. Check voltage between ECM terminal 46 and ground and note 9. Drain fuel by 30 (7-7/8 US gal, 6-5/8 Imp gal) from the fuel 10. Fill fuel into the fuel tank for 30 (7-7/8 US gal, 6-5/8 Imp gal). 11. Confirm that the voltage between ECM terminal 46 and ground changes more than 0.03V during step 8 - 10. "FUEL LEVEL SENSOR UNIT CHECK" SEF802Z |
