PG-48

< DTC/CIRCUIT DIAGNOSIS >

HARNESS

CHASSIS HARNESS

ABMIA3531GB

G3 C1

SMJ

: To E41

Differential sub-harness

D3 C5

GR/5

: Fuel level sensor unit and fuel pump

B4

C115

GR/4

: To C14

A3

C6

B/2

: EVAP canister vent control valve

C4 C116

GR/2

: Differential lock position switch

A3

C7

GR/3

: EVAP control system pressure sensor

C4 C117

B/2

: Differential lock solenoid

D4 C10

GR/2

: Rear wheel sensor RH

Trailer sub-harness

PG

HARNESS

PG-49

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

BODY HARNESS

C3 C11

BR/2

: Rear wheel sensor LH

B4

C125

GR/6

: To C51

A4

C12

W/2

: License plate lamp

A5

C126

B/7

: Trailer

B4

C14

GR/4

: To C115

B5

C129

B/7

: Trailer receptacle

B4

C51

GR/6

: To C125

A4

C150

B/2

: To C52

A4

C52

B/2

: To C150

ABMIA5603ZZ

PG-50

< DTC/CIRCUIT DIAGNOSIS >

HARNESS

D4 B6

W/12

: To D201

G2 B48

W/16

: To D402

B5

B7

—

: Body ground

G2 B50

W/2

: To D410

C4 B8

W/3

: Front door switch LH

A4

B69

SMJ

: To M40

C4 B9

Y/22

: Air bag diagnosis sensor unit

C5 B72

W/4

: Subwoofer

C4 B10

Y/2

: Front LH side air bag module

C4 B73

B/4

: Yaw rate/side/decel G sensor

B5

B11

—

: Body ground

B4

B78

Y/2

: To B157

C4 B12

W/4

: Seat belt buckle switch LH

B4

B79

W/6

: To B500

D5 B14

Y/2

: Front LH seat belt pre-tensioner

A1

B82

Y/2

: RH side curtain air bag module

C5 B15

Y/2

: LH side air bag (satellite) sensor

B5

B83

W/3

: Front seat heater LH

E3

B18

W/3

: Rear door switch LH

C4 B84

B/1

: Parking brake switch

G3 B19

—

: Body ground

G3 B85

—

: Body ground

G3 B35

W/6

: Rear combination lamp LH

Off-road lamps sub-harness

C2 B38

Y/2

: LH side curtain air bag module

B3

B500

W/6

: To B79

B5

B40

W/8

: To E34

B2

B501

GR/6

: To B526

B5

B42

W/2

: To E36

PG

HARNESS

PG-51

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

BODY NO. 2 HARNESS

ABMIA5604ZZ

B3

B105

W/6

: Rear combination lamp RH

B2

B138

B/3

: Rear cargo power socket

E4

B106

W/12

: To D301

E5

B141

W/32

: Bluetooth® control unit

E4

B108

W/3

: Front door switch RH

F5

B143

W/8

: Bluetooth® control unit

F4

B110

W/4

: Seat belt buckle switch RH

G5 B149

SMJ

: To M36

F4

B113

Y/22

: Air bag diagnosis sensor unit

G4 B157

Y/2

: To B78
