Noise, Vibration and Harshness (NVH) =NMAX0004 NVH TROUBLESHOOTING CHART NMAX0004S01 Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts. Reference page — AX-17 — — Refer to DRIVE SHAFT in this chart. Refer to AXLE in this chart. SU-4 SU-4 BR-5 ST -5 Possible cause and Excessive joint angle Joint sliding resistance Imbalance Improper installation, looseness Parts interference Wheel bearing damage PROPELLER SHAFT DIFFERENTIAL DRIVE SHAFT AXLE SUSPENSION TIRES ROAD WHEEL BRAKES STEERING Symptom DRIVE Noise, Vibration × × × × × × × × × × Shake × × × × × × × × × AXLE Noise × × × × × × × × × × Shake × × × × × × × × × Vibration × × × × × × × Shimmy × × × × × × × Judder × × × × × × Poor quality ride × × × × × × × : Applicable SMA525A On-vehicle Service FRONT AXLE PARTS NMAX0005 Check front axle and front suspension parts for excessive play, I Shake each front wheel to check for excessive play. I Make sure that cotter pin is inserted. I Retighten all axle and suspension nuts and bolts to the speci- Tightening torque: Refer to SU-9, “FRONT SUSPENSION”. GI MA EM LC EC FE CL MT AT PD SU BR ST RS BT HA SC EL IDX FRONT AXLE Noise, Vibration and Harshness (NVH) Troubleshooting AX-3 |
