8. Large Shock. “N” → “R” Position =NMAT0077 SYMPTOM: 1 CHECK SELF-DIAGNOSTIC RESULTS Does self-diagnosis show damage to A/T fluid temperature sensor, line pressure solenoid valve or throttle position sensor SAT831HA Yes or No Yes © Check damaged circuit. Refer to AT-98, AT-125 or AT-136. No © GO TO 2. 2 CHECK THROTTLE POSITION SENSOR Check throttle position sensor. Refer to EC-141, “Component Description”. SAT414K OK or NG OK © GO TO 3. NG © Repair or replace throttle position sensor. GI MA EM LC EC FE CL MT PD AX SU BR ST RS BT HA SC EL IDX TROUBLE DIAGNOSES FOR SYMPTOMS 8. Large Shock. “N” → “R” Position AT-157 |
