Nissan Silvia. Manual - part 1

AUTOMATIC TRANSMISSION

SECTION

CONTENTS

PRECAUTIONS ...............................................................4

Supplemental Restraint System (SRS)

............................................................................4

Precautions ..................................................................4
Service Notice or Precautions .....................................5
Wiring Diagrams and Trouble Diagnosis.....................6

PREPARATION ...............................................................7

Special Service Tools ..................................................7

A/T FLUID ........................................................................9

Checking A/T Fluid ......................................................9
Changing A/T Fluid ......................................................9

OVERALL SYSTEM ...................................................... 11

A/T Electrical Parts Location ..................................... 11
Circuit Diagram ..........................................................12
Cross-sectional View .................................................13
Hydraulic Control Circuit............................................14
Shift Mechanism ........................................................15
Control System ..........................................................24
Control Mechanism....................................................25
Control Valve .............................................................30

ON BOARD DIAGNOSTIC SYSTEM
DESCRIPTION ...............................................................32

CONSULT-II ...............................................................32
Diagnostic Procedure Without CONSULT-II..............37

TROUBLE DIAGNOSIS - INTRODUCTION..................42

Introduction ................................................................42
Work Flow..................................................................46

TROUBLE DIAGNOSIS - BASIC INSPECTION ...........48

A/T Fluid Check .........................................................48
Stall Test ....................................................................48
Line Pressure Test.....................................................51
Road Test...................................................................52

TROUBLE DIAGNOSIS - GENERAL
DESCRIPTION ...............................................................70

Symptom Chart..........................................................70
TCM Terminals and Reference Value........................82

TROUBLE DIAGNOSIS FOR POWER SUPPLY..........86

Wiring Diagram - AT - MAIN......................................86
Diagnostic Procedure ................................................87

TROUBLE DIAGNOSIS FOR VHCL SPEED
SEN.A/T (REVOLUTION SENSOR)..............................89

Description .................................................................89
Wiring Diagram - AT - VSSA/T ..................................91
Diagnostic Procedure ................................................92
Component Inspection...............................................93

TROUBLE DIAGNOSIS FOR VHCL SPEED
SEN.MTR .......................................................................95

Description .................................................................95
Wiring Diagram - AT - VSSMTR................................96
Diagnostic Procedure ................................................97

TROUBLE DIAGNOSIS FOR THROTTLE POSI
SEN ................................................................................98

Description .................................................................98
Wiring Diagram - AT - TPS......................................100
Diagnostic Procedure ..............................................101
Component Inspection.............................................105

TROUBLE DIAGNOSIS FOR SHIFT SOLENOID/V
A ...................................................................................106

Description ...............................................................106
Wiring Diagram - AT - SSV/A ..................................108
Diagnostic Procedure ..............................................109
Component Inspection............................................. 110

TROUBLE DIAGNOSIS FOR SHIFT SOLENOID/V
B ................................................................................... 111

Description ............................................................... 111
Wiring Diagram - AT - SSV/B .................................. 113
Diagnostic Procedure .............................................. 114
Component Inspection............................................. 115

TROUBLE DIAGNOSIS FOR OVERRUN CLUTCH
S/V................................................................................ 116

Description ............................................................... 116
Wiring Diagram - AT - OVRCSV.............................. 117
Diagnostic Procedure .............................................. 118
Component Inspection............................................. 119

TROUBLE DIAGNOSIS FOR T/C CLUTCH SOL/V ...120

Description ...............................................................120
Wiring Diagram - AT - TCV......................................122
Diagnostic Procedure ..............................................123

IDX

Component Inspection.............................................124

TROUBLE DIAGNOSIS FOR BATT/FLUID TEMP
SEN ..............................................................................125

Description ...............................................................125
Wiring Diagram - AT - BA/FTS ................................127
Diagnostic Procedure ..............................................128
Component Inspection.............................................131

TROUBLE DIAGNOSIS FOR ENGINE SPEED SIG ..132

Description ...............................................................132
Wiring Diagram - AT - ENGSS ................................133
Diagnostic Procedure ..............................................134

TROUBLE DIAGNOSIS FOR LINE PRESSURE
S/V................................................................................136

Description ...............................................................136
Wiring Diagram - AT - LPSV....................................138
Diagnostic Procedure ..............................................139
Component Inspection.............................................140

TROUBLE DIAGNOSIS FOR CONTROL UNIT
(RAM), CONTROL UNIT (ROM) .................................142

Description ...............................................................142
Diagnostic Procedure ..............................................143

TROUBLE DIAGNOSIS FOR CONTROL UNIT
(EEPROM)....................................................................144

Description ...............................................................144
Diagnostic Procedure ..............................................145

TROUBLE DIAGNOSES FOR SYMPTOMS ...............146

Wiring Diagram - AT - NONDTC .............................146
1. POWER Indicator Lamp Does Not Come On.....149
2. POWER or SNOW Indicator Lamp Does Not
Come On .................................................................150
3. O/D OFF Indicator Lamp Does Not Come On....151
4. POWER Indicator Lamp Does Not Come On.....152
5. Engine Cannot Be Started In

″

and

″

Position ....................................................................153
6. In

″

Position, Vehicle Moves Forward Or

Backward When Pushed .........................................154
7. In

″

Position, Vehicle Moves ...........................155

8. Large Shock.

″

Position .......................157

9. Vehicle Does Not Creep Backward In

″

Position ....................................................................159
10. Vehicle Does Not Creep Forward In

″

Position.........................................................162

11. Vehicle Cannot Be Started From D

.................165

12. A/T Does Not Shift: D

..................................................168

13. A/T Does Not Shift: D

-> D

.............................171

14. A/T Does Not Shift: D

-> D

.............................174

15. A/T Does Not Perform Lock-up .........................177
16. A/T Does Not Hold Lock-up Condition ..............179
17. Lock-up Is Not Released...................................181
18. Engine Speed Does Not Return To Idle (Light
Braking D

-> D

).....................................................182

19. Vehicle Does Not Start From D

.......................184

20. A/T Does Not Shift: D

-> D

, When

Overdrive Control Switch

″

OFF

″

...............185

21. A/T Does Not Shift: D

Position.........................................186

22. A/T Does Not Shift: 2

Position .........................................187

23. Vehicle Does Not Decelerate By Engine
Brake........................................................................188
24. TCM Self-diagnosis Does Not Activate (PNP,
Overdrive Control, A/T Check and TP Switches
Circuit Checks) ........................................................189

A/T SHIFT LOCK SYSTEM.........................................198

Description ...............................................................198
Wiring Diagram - SHIFT -........................................199
Diagnostic Procedure ..............................................200
Component Check ...................................................202

KEY INTERLOCK CABLE ..........................................203

Removal...................................................................203
Installation................................................................203

SHIFT CONTROL SYSTEM ........................................204

Control Device .........................................................204

ON-VEHICLE SERVICE ..............................................205

Control Valve Assembly and Accumulators.............205
Revolution Sensor Replacement .............................205
Rear Oil Seal Replacement.....................................206
Parking Pawl Components Inspection.....................206
Park/Neutral Position Switch Adjustment ................206
Manual Control Linkage Adjustment........................207

REMOVAL AND INSTALLATION ...............................208

Removal...................................................................208
Installation................................................................209

OVERHAUL ................................................................. 211

Components............................................................. 211
Oil Channel ..............................................................213
Locations of Needle Bearings, Thrust Washers
and Snap Rings .......................................................214

DISASSEMBLY............................................................215
REPAIR FOR COMPONENT PARTS .........................226

Oil Pump ..................................................................226
Control Valve Assembly...........................................230
Control Valve Upper Body .......................................236
Control Valve Lower Body .......................................241
Reverse Clutch ........................................................243
High Clutch ..............................................................246
Forward and Overrun Clutches ...............................249
Low & Reverse Brake..............................................253
Forward Clutch Drum Assembly..............................257
Rear Internal Gear and Forward Clutch Hub ..........259
Band Servo Piston Assembly ..................................262
Parking Pawl Components ......................................266

ASSEMBLY..................................................................268

CONTENTS

(Cont’d)

AT-2

Assembly (1)............................................................268
Adjustment ...............................................................276
Assembly (2)............................................................279

A/T FLUID COOLER SYSTEM ...................................286

A/T Fluid Cooler.......................................................286

SERVICE DATA AND SPECIFICATIONS (SDS) .......288

General Specifications.............................................288
Shift Schedule..........................................................288
Stall Revolution........................................................288

Line Pressure...........................................................288
Return Springs.........................................................289
Accumulator O-ring..................................................290
Clutches and Brakes ...............................................290
Oil Pump and Low One-way Clutch ........................292
Total End Play..........................................................292
Reverse Clutch Drum End Play ..............................293
Removal and Installation .........................................293

IDX

CONTENTS

(Cont’d)

AT-3

Supplemental Restraint System (SRS) “AIR
BAG”

NMAT0253

The Supplemental Restraint System such as “AIR BAG” used along with a seat belt, helps to reduce the risk
or severity of injury to the driver and front passenger for certain types of collision. The SRS system composi-
tion which is available to NISSAN MODEL S15 is as follows:
The Supplemental Restraint System consists of driver air bag module (located in the center of the steering
wheel), front passenger air bag module (located on the instrument panel on passenger side), a diagnosis
sensor unit, warning lamp, wiring harness and spiral cable.
Information necessary to service the system safely is included in the RS section of this Service Manual.

WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance should be per-
formed by an authorized NISSAN dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the RS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified with yellow harness connector.

SEF289H

Precautions

NMAT0003

Before connecting or disconnecting the TCM harness
connector, turn ignition switch “OFF” and disconnect
negative battery terminal. Failure to do so may damage
the TCM. Because battery voltage is applied to TCM even
if ignition switch is turned “OFF”.

AAT470A

When connecting or disconnecting pin connectors into or
from TCM, take care not to damage pin terminals (bend or
break).
Make sure that there are not any bends or breaks on TCM
pin terminal, when connecting pin connectors.

MEF040DA

Before replacing TCM, perform TCM input/output signal
inspection and make sure whether TCM functions prop-
erly or not. (Refer to AT-82.)

PRECAUTIONS

Supplemental Restraint System (SRS) “AIR BAG”

AT-4

Content .. 1 2 3 ..
