EC-422 [QG (WITH EURO-OBD)] DTC P1144 HO2S1 (M/T MODELS) DTC Confirmation Procedure EBS00QQ6 CAUTION: Always drive vehicle at a safe speed. TESTING CONDITION: ● Always perform at a temperature above − 10 ° C (14 ° F). ● Before performing the following procedure, confirm that battery voltage is more than 11V at idle. WITH CONSULT-II 1. Start engine and warm it up to normal operating temperature. 2. Stop engine and wait at least 5 seconds. 3. Turn ignition switch “ON” and select “HO2S1 (B1) P1144” of “HO2S1” in “DTC WORK SUPPORT” mode 4. Touch “START”. 5. Start engine and let it idle for at least 3 minutes. NOTE: 6. When the following conditions are met, “TESTING” will be dis- If “TESTING” is not displayed after 5 minutes, retry from 7. Make sure that “OK” is displayed after touching “SELF-DIAG . PBIB0548E ENG SPEED 1,700 - 2,600 rpm Vehicle speed 50 - 100 km/h (30 - 62 MPH) B/FUEL SCHDL 3.0 - 5.2 msec Selector lever Suitable position PBIB0549E SEC772C |
