AV MULTI AV SYSTEM AV-111 < SYSTEM DESCRIPTION > [BOSE AUDIO WITH NAVIGATION] C D E F G H I J K L M B A O P Driving History Information Display Mode Displays the sub-functions (driving route history and required time Fail-Safe INFOID:0000000009163338 When the ambiance temperature becomes extremely low or extremely high, AV control unit displays the mes- FAIL-SAFE CONDITIONS When the ambiance temperature is − 20 ° C ( − 4 ° F) or lower, or when it is 70 ° C (158 ° F) or higher Display The messages displayed on fail-safe conditions are as shown below: Display Display item Description Signal route Display form Display range Unit GEAR POSI- GEAR Selected gear position Position sensor → TCM → Combination meter → AV control unit Value/ symbol R, P, N, 1 - 6 — SPEED Vehicle speed Wheel sensor → ABS actuator and electric → AV control unit Value 0 - 340 km/h 0 - 215 MPH GEAR Displays ECO/power band per TCM → Combination meter → AV control unit Special display — — FUEL ECONO- FUEL EFFICIENCY Displays the current ECO level. ECM/TCM/Combina- → AV control unit Gauge 10 levels — FUEL ECON Interval fuel consumption ECM/Combination → AV control unit Value 0 - 30 l/100 km Graph 0 - 30 Value 0 - 60 MPG Graph 0 - 30 FUEL EFFICIENCY Displays the history of an aver- ECM/TCM/Combina- → AV control unit Graph 10 levels — NNNIA0169ZZ Display Description Display form STOP WATCH Displays the measured TIME results. Special display DRIVER'S NOTES Displays the driving history information Special display Fail-safe mode Display (display of the fail-safe condition) When HDD temperature is low HDD system is experiencing problems due to extreme low temperature. When HDD temperature is high HDD system is experiencing problems due to extreme high temperature. |
