VEHICLE SECURITY INDICATOR SEC-147 < DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM] C D E F G H I J L M A B SEC N O P 3. Check continuity between BCM connector M18 (A) terminal 23 and combination meter connector M24 (B) terminal 39. 4. Check continuity between BCM connector M18 (A) terminal 23 and ground. Is the inspection result normal? YES >> Check the following: • 10A fuse [No. 19, located in fuse block (J/B)] • Harness for open or short between security indicator lamp and fuse NO >> Repair or replace harness. 23 - 39 : Continuity should exist. 23 - Ground : Continuity should not exist. ALKIA1273ZZ 2011 Pathfinder |
