INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION

SEC-83

< WIRING DIAGRAM >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

ABKIA0351GB

2011 Pathfinder

SEC-84

< WIRING DIAGRAM >

[WITH INTELLIGENT KEY SYSTEM]

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION

ABKIA3016GB

2011 Pathfinder

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION

SEC-85

< WIRING DIAGRAM >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

ABKIA2888GB

2011 Pathfinder

SEC-86

< WIRING DIAGRAM >

[WITH INTELLIGENT KEY SYSTEM]

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION

ABKIA2889GB

2011 Pathfinder

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION

SEC-87

< WIRING DIAGRAM >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

ABKIA2890GB

2011 Pathfinder

SEC-88

< WIRING DIAGRAM >

[WITH INTELLIGENT KEY SYSTEM]

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION

ABKIA1755GB

2011 Pathfinder

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION

SEC-89

< WIRING DIAGRAM >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

ABKIA1756GB

2011 Pathfinder

SEC-90

< WIRING DIAGRAM >

[WITH INTELLIGENT KEY SYSTEM]

INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION

ABKIA1757GB

2011 Pathfinder
