C1116 STOP LAMP SWITCH BRC-161 < DTC/CIRCUIT DIAGNOSIS > [TYPE 2] C D E G H I J K L M A B BRC N O P 1. Disconnect stop lamp relay connector. 2. Check continuity between stop lamp relay connector E12 (A) terminal 5 and ABS actuator and electric unit (control unit) con- nector E127 (B) terminal 41. Is the inspection result normal? YES >> Refer to NO >> Repair or replace malfunctioning components. Special Repair Requirement INFOID:0000000006689895 1. ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION Always perform neutral position adjustment for the steering angle sensor when replacing the ABS actuator and electric unit (control unit). Refer to BRC-121, "ADJUSTMENT OF STEERING ANGLE SENSOR NEU- >> GO TO 2 2. CALIBRATION OF DECEL G SENSOR Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit). BRC-122, "CALIBRATION OF DECEL G SENSOR : Description" . >> END Continuity should exist. AWFIA0479ZZ 2011 Pathfinder |
