B1033 – B1035 CRASH ZONE SENSOR SRC-47 < COMPONENT DIAGNOSIS > C D E F G I J K L M A B SRC N O P B1033 – B1035 CRASH ZONE SENSOR Description INFOID:0000000003937617 DTC B1033 – B1035 CRASH ZONE SENSOR The crash zone sensor is wired to the air bag diagnosis sensor unit. The air bag diagnosis sensor unit will PART LOCATION SRC-7, "SRS Component Parts Location" DTC Logic INFOID:0000000003937618 DTC DETECTION LOGIC With CONSULT-lll Without CONSULT-lll DTC CONFIRMATION PROCEDURE (With CONSULT-lll) 1. INSPECTION START Turn ignition switch ON. >> GO TO 2. 2. CHECK SELF-DIAG RESULT Check for the DTC on CONSULT-lll. Is the DTC detected? YES >> Refer to SRC-48, "Diagnosis Procedure (Component Diagnosis)" . NO >> Inspection End. DTC CONFIRMATION PROCEDURE (Without CONSULT-lll) NOTE: 1. IGNITION SWITCH Turn ignition switch ON. >> GO TO 2 CONSULT-III name DTC DTC detecting condition Repair order CRASH ZONE SEN [UNIT FAIL] B1033 Crash zone sensor has malfunctioned. 1. Visually check the wiring harness connection. 2. Replace the harness if it has visible damage. 3. Replace the crash zone sensor. 4. Replace the air bag diagnosis sensor unit. 5. Replace the related harness. B1034 CRASH ZONE SEN [COMM FAIL] B1035 Crash zone sensor communication error. WHIA0200E 2009 Pathfinder |
