Nissan Pathfinder (2009 year). Manual - part 432





PLEASE HELP MAKE THIS SERVICE MANUAL BETTER!

Your comments are important to NISSAN and will help us to improve our Service Manuals.
Use this form to report any issues or comments you may have regarding our Service Manuals.
Please print this form and type or write your comments below. Mail or fax to:

Nissan North America, Inc.
Technical Service Information
39001 Sunrise Drive, P.O. Box 9200
Farmington Hills, MI USA 48331
FAX: (248) 488-3910

SERVICE MANUAL: Model:

Year:

PUBLICATION NO. (Refer to Quick Reference Index ):

Please describe any Service Manual issues or problems in detail:
Page number(s)

Note: Please include a copy of each page, marked with your comments.

Are the trouble diagnosis procedures logical and easy to use? (circle your answer)

YES

NO

If no, what page number(s)?

Note: Please include a copy of each page, marked with your comments.

Please describe the issue or problem in detail:

Is the organization of the manual clear and easy to follow? (circle your answer)

YES

NO

Please comment:

What information should be included in NISSAN Service Manuals to better support you in servicing or
repairing customer vehicles?

DATE:

YOUR NAME:

POSITION:

DEALER:

DEALER NO.:

ADDRESS:

CITY:

STATE/PROV./COUNTRY:

ZIP/POSTAL CODE:

20

09

QUICK REFERENCE CHART: PATHFINDER

QUICK REFERENCE CHART: PATHFINDER

Engine Tune-up Data: VQ40DE

INFOID:0000000001733188

GENERAL SPECIFICATIONS

Cylinder arrangement

V-6

Displacement cm

3

(cu in)

3,954 (241.30)

Bore and stroke mm (in)

95.5

×

 92.0 (3.76

×

 3.622)

Valve arrangement

DOHC

Firing order

1-2-3-4-5-6

Number of piston rings

Compression

2

Oil

1

Number of main bearings

4

Compression ratio

9.7

Compression pressure                                  kPa
(kg/cm

2

, psi)/300 rpm

Standard

1,275 (13.0, 185)

Minimum

981 (10.0, 142)

Differential limit between cylinders

98 (1.0, 14)

Cylinder number

Valve timing

(Intake valve timing control - “OFF”)

Unit: degree

a

b

c

d

e

f

244

240

4

64

6

58

SEM713A

PBIC0187E

QUICK REFERENCE CHART: PATHFINDER

20

09

Engine Tune-up Data : VK56DE

INFOID:0000000001733189

GENERAL SPECIFICATIONS

Cylinder arrangement

V-8

Displacement cm

3

 (in

3

)

5,552 (338.80)

Bore and stroke mm (in)

98 x 92 (3.86 x 3.62)

Valve arrangement

DOHC

Firing order

1-8-7-3-6-5-4-2

Number of piston rings

Compression

2

Oil

1

Number of main bearings

5

Compression ratio

9.8:1

Compression pressure                                  kPa
(kg/cm

2

, psi)/rpm

Standard

1,520 (15.5, 220)/200

Minimum

1,324 (13.5, 192)/200

Differential limit between cylinders

98 (1.0, 14)/200

Cylinder number

Valve timing

Unit: degree

a

b

c

d

e

f

244

°

232

°

8

°

60

°

10

°

54

°

SEM957C

PBIC0187E

200

9

QUICK REFERENCE CHART: PATHFINDER

Front Wheel Alignment (Unladen*1)

INFOID:0000000001733190

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
*2: Target value 35

°

 26

 (35.43

°

)

*3: Target value 31

°

 22

 (31.37

°

)

*4: Target value 35

°

 33

 (35.55

°

)

*5: Target value 31

°

 38

 (31.63

°

)

Rear Wheel Alignment

INFOID:0000000001733191

Drive type

2WD

4WD

Camber

Degree minute (decimal degree)

Minimum

-0

°

 30

 (-0.50

°

)

-0

°

 15

 (-0.25

°

)

Nominal

0

°

 15

 (0.25

°

)

0

°

 30

 (0.50

°

)

Maximum

1

°

 00

 (1.00

°

)

1

°

 15

 (1.25

°

)

Cross camber

0

°

 45

 (0.75

°

) or less

 0

°

 45

 (0.75

°

) or less

Caster

Degree minute (decimal degree)

Minimum

2

°

 15

 (2.25

°

)

2

°

 00

 (2.00

°

)

Nominal

3

°

 0

 (3.00

°

)

2

°

 45

 (2.75

°

)

Maximum

3

°

 45

 (3.75

°

)

3

°

 30

 (3.50

°

)

Cross caster

0

°

 45

 (0.75

°

) or less

0

°

 45

 (0.75

°

) or less

Kingpin inclination

Degree minute (decimal degree)

Nominal

13

°

 0

 (13.00

°

)

12

°

 45

 (12.75

°

)

Total toe-in

Distance (A

 B)

Minimum

2.1 mm (0.08 in)

2.1 mm (0.08 in)

Nominal

3.1 mm (0.12 in)

3.1 mm (0.12 in)

Maximum

4.1 mm (0.16 in)

4.1 mm (0.16 in)

Angle (left wheel or right wheel)

Degree minute (decimal degree)

Minimum

0

°

 5

 (0.08

°

)

0

°

 5

 (0.08

°

)

Nominal

0

°

 7

 (0.12

°

)

0

°

 7

 (0.12

°

)

Maximum

0

°

 9

 (0.15

°

)

0

°

 9

 (0.15

°

)

Wheel turning angle (full turn)

Inside

Degree minute (Decimal degree)

33

°

 26

 – 35

°

 26

 *

2

(33.43

°

 – 35.43

°

)

33

°

 33

 – 35

°

 33

 *

4

(33.60

°

 – 35.60

°

)

Outside

Degree minute (Decimal degree)

29

°

 22

 – 31

°

 22

 *

3

(29.37

°

 – 31.37

°

)

29

°

 38

 – 31

°

 38

 *

5

(29.73

°

 – 31.73

°

)

SFA234AC

Camber

Degree minute (decimal degree)

Minimum

- 0

°

 32

 (- 0.53

°

)

Nominal

- 0

°

 2

 (- 0.03

°

)

Maximum

0

°

 28

 (0.47

°

)

QUICK REFERENCE CHART: PATHFINDER

200

9

Wheelarch Height (Unladen*)

INFOID:0000000001733192

Unit: mm (in)

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.

Brake General Specification

INFOID:0000000001733193

Unit: mm (in)

Total toe-in

Distance (A - B)

Minimum

- 1.4 mm (- 0.055 in)

Nominal

1.9 mm (0.075 in)

Maximum

5.2 mm (0.205 in)

Cross toe

±

 2 mm (0

±

 0.079 in)

Angle (left, right)

Degree minute (decimal degree)

Minimum

- 0

°

 3' (-0.05

°

)

Nominal

0

°

 4' (0.07

°

)

Maximum

0

°

 11' (0.18

°

)

SFA234AC

Engine

VQ40DE

VK56DE

Drive type

2WD

Part time 4WD

Full time

4WD

2WD

4WD

Tire size

245/

75R16

265/

70R16

265/

65R17

245/

75R16

265/

70R16

265/

75R16

265/

65R17

265/60R18

Front wheelarch

height (Hf)

867

(34.13)

865

(34.06)

865

(34.06)

875

(34.45)

873

(34.37)

889

(35.00)

874

(34.41)

868

(34.17)

876

(34.49)

Rear wheelarch

height (Hr)

875

(34.45)

873

(34.37)

873

(34.37)

884

(34.80)

882

(34.72)

898

(35.35)

883

(34.76)

876

(34.49)

886

(34.88)

LEIA0085E

Front brake

Brake model

CLZ33VB

Rotor outer diameter

×

 thickness

296

×

 28 (11.654

×

 1.102)

Pad Length

×

 width

×

 thickness

111.0

×

 73.5

×

 10.0 (4.73

×

 2.894

×

 0.394)

Cylinder bore diameter (each)

46.4 (1.83)

200

9

QUICK REFERENCE CHART: PATHFINDER

Brake Pedal

INFOID:0000000001733194

Unit: mm (in)

Front Disc Brake

INFOID:0000000001733195

Unit: mm (in)

Rear brake

Brake model

CLZ14VB

Rotor outer diameter

×

 thickness

308

×

 18 (12.126

×

 0.709)

Pad Length

×

 width

×

 thickness

83.0

×

 33.0

×

 11.0 (3.268

×

 1.299

×

 0.433)

Cylinder bore diameter

38.1 (1.50)

Control valve

Valve model

Electric brake force distribution

Brake booster

Booster model

C215T

Diaphragm diameter

215 (8.46)

Recommended brake fluid

Refer to Fluids and Lubricants

Free height "H"

182.1 - 192.1 (7.17 - 7.56)

Depressed pedal height ("D" [under a force of 490 N (50 kg, 110 lb) with

engine running]

105 - 115 (4.13 - 4.53)

Clearance between pedal stopper and threaded end of stop lamp switch

and ASCD switch "C

1

" or “C

2

0.74 - 1.96 (0.029 - 0.077)

Pedal play "A"

3 - 11 (0.12 - 0.43)

WFIA0160E

Brake model

CLZ33VB

Brake pad

Standard thickness (new)

10.0 (0.394)

Repair limit thickness

2.0 (0.079)

Disc rotor

Standard thickness (new)

28.0 (1.102)

Repair limit thickness

26.0 (1.024)

Maximum uneven wear (measured at 8 positions)

0.015 (0.0006)

Runout limit (with it attached to the vehicle)

0.05 (0.0020)

QUICK REFERENCE CHART: PATHFINDER

200

9

Rear Disc Brake

INFOID:0000000001733196

Unit: mm (in)

Fluids and Lubricants

INFOID:0000000001733197

Brake model

CLZ14VB

Brake pad

Standard thickness (new)

11.0 (0.433)

Repair limit thickness

2.0 (0.079)

Disc rotor

Standard thickness (new)

18.0 (0.709)

Repair limit thickness

16.0 (0.630)

Maximum uneven wear (measured at 8 positions)

0.015 (0.0006)

Runout limit (with it attached to the vehicle)

0.05 (0.0020)

Description

Capacity (Approximate)

Metric

US measure

Imp measure

Fuel

80

21 1/8 gal

17 5/8 gal

Engine oil

Drain and refill

With oil filter

change

VQ40DE

5.1

5 3/8 qt

4 1/2 qt

VK56DE

6.2

6 1/2 qt

5 1/2 qt

Without oil filter

change

VQ40DE

4.8

5 1/8 qt

4 1/4 qt

VK56DE

5.9

6 1/4 qt

5 1/4 qt

Dry engine (engine overhaul)

VQ40DE

6.3

 6 5/8 qt

5 1/2 qt

VK56DE

7.6

 8 qt

6 3/4 qt

Cooling system

(with reservoir at “MAX”

level)

Without rear A/C

10.2

2 3/4 gal

2 1/4 gal

With rear A/C

13.4

3 1/2 gal

3 gal

Automatic transmission fluid (ATF)

10.3

10 7/8 qt

9 1/8 qt

Rear final drive oil

VQ40DE

1.4

3 pt

2 1/2 pt

VK56DE

1.75

3 3/4 pt

3 1/8 pt

Transfer fluid

ATX14B

3.0

3 1/8 qt

2 5/8 qt

TX15B

2.0

2 1/8 qt

1 3/4 qt

Front final drive oil

VQ40DE

0.85

1 3/4 pt

1 1/2 pt

VK56DE

1.6

3 3/8 pt

2 7/8 pt

Power steering fluid (PSF)

1.0

2 1/8 pt

1 3/4 pt

Brake fluid

Multi-purpose grease

Windshield washer fluid

4.5

1 1/4 gal

1 gal

A/C system refrigerant

Without rear A/C

0.70

±

 0.05 kg

1.54

±

 0.11 lb

1.54

±

 0.11 lb

With rear A/C

0.85

±

 0.05 kg

1.87

±

 0.11 lb

1.87

±

 0.11 lb

A/C system oil

Without rear A/C

180 m

6.1 fl oz

6.3 fl oz

With rear A/C

210 m

7.1 fl oz

7.4 fl oz

GI-1

GENERAL INFORMATION

C

D

E

F

G

H

I

J

K

L

M

B

GI

SECTION

GI

N

O

P

CONTENTS

GENERAL INFORMATION

HOW TO USE THIS MANUAL ......................

3

HOW TO USE THIS MANUAL  ............................

3

Description ................................................................

3

Terms ........................................................................

3

Units ..........................................................................

3

Contents ....................................................................

3

Component ................................................................

3

How to Follow Trouble Diagnosis ..............................

4

How to Read Wiring Diagram ....................................

8

Abbreviations ..........................................................

15

HOW TO FOLLOW TROUBLE DIAGNOSES ....

17

Description ..............................................................

17

How to Follow Test Groups in Trouble Diagnosis ....

17

Key to Symbols Signifying Measurements or Pro-
cedures ...................................................................

18

HOW TO READ WIRING DIAGRAMS  ...............

20

Connector symbols  .................................................

20

Sample/wiring diagram -example- ...........................

21

Description ..............................................................

22

ABBREVIATIONS ..............................................

24

Abbreviation List ......................................................

24

TIGHTENING TORQUE OF STANDARD
BOLTS ................................................................

25

Tightening Torque Table  .........................................

25

RECOMMENDED CHEMICAL PRODUCTS
AND SEALANTS ................................................

26

Recommended Chemical Products and Sealants

....

26

TERMINOLOGY .................................................

27

ISO 15031-2 Terminology List  ................................

27

TIGHTENING TORQUE OF STANDARD
BOLTS ................................................................

31

Tightening Torque Table  .........................................

31

FEATURES OF NEW MODEL .....................

32

IDENTIFICATION INFORMATION ....................

32

Model Variation ........................................................

32

Identification Number ...............................................

33

Dimensions ..............................................................

35

Wheels & Tires  ........................................................

35

PRECAUTION ..............................................

36

PRECAUTIONS .................................................

36

Description ...............................................................

36

Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .................................................................

36

Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect  ...................................

36

General Precaution ..................................................

37

Precaution for All Mode 4WD System  .....................

38

Precaution for Three Way Catalyst ..........................

38

Precaution for Fuel (Unleaded Premium Gasoline
Recommended) .......................................................

38

Precaution for Multiport Fuel Injection System or
Engine Control System ............................................

39

Precaution for Hoses  ...............................................

39

Precaution for Engine Oils .......................................

40

Precaution for Air Conditioning ................................

40

LIFTING POINT .................................................

41

Pantograph Jack ......................................................

41

Garage Jack and Safety Stand ................................

41

2-Pole Lift  ................................................................

41

TOW TRUCK TOWING  .....................................

43

Tow Truck Towing  ...................................................

43

Vehicle Recovery (Freeing a Stuck Vehicle)  ...........

44

BASIC INSPECTION  ...................................

45

SERVICE INFORMATION FOR ELECTRICAL
INCIDENT ..........................................................

45

Work Flow ................................................................

45

Control Units and Electrical Parts ............................

45

How to Check Terminal  ...........................................

46

2009 Pathfinder















Content      ..     430      431      432      433     ..
