BCM (BODY CONTROL MODULE)

ADP-147

< ECU DIAGNOSIS >

ADP

Fail Safe

INFOID:0000000004432036

Fail-safe index

BCM performs fail-safe control when any DTC listed below is detected.

ABMIA0162GB

2009 Pathfinder

ADP-148

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

DTC Inspection Priority Chart

INFOID:0000000004432037

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.

DTC Index

INFOID:0000000004432038

NOTE:

Details of time display

• CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning igni-

tion switch OFF

→

ON again.

• 1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases like 1

→

3...38

→

39 after returning to the normal condition whenever ignition switch OFF

→

ON. The counter

remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch
OFF

→

ON after returning to the normal condition if the malfunction is detected again.

Display contents of CONSULT

Fail-safe

Cancellation

U1000: CAN COMM CIRCUIT

Inhibit engine cranking

When the BCM re-establishes communication with the other mod-
ules.

U1010: CONTROL UNIT (CAN)

Inhibit engine cranking

When the BCM re-start communicating with the other modules.

Priority

DTC

• U1000: CAN COMM CIRCUIT
• U1010: CONTROL UNIT (CAN)

• B2190: NATS ANTENNA AMP
• B2191: DIFFERENCE OF KEY
• B2192: ID DISCORD BCM-ECM
• B2193: CHAIN OF BCM-ECM
• B2013: STRG COMM 1
• B2552: INTELLIGENT KEY
• B2590: NATS MALFUNCTION

• C1729: VHCL SPEED SIG ERR
• C1735: IGNITION SIGNAL

• C1704: LOW PRESSURE FL
• C1705: LOW PRESSURE FR
• C1706: LOW PRESSURE RR
• C1707: LOW PRESSURE RL
• C1708: [NO DATA] FL
• C1709: [NO DATA] FR
• C1710: [NO DATA] RR
• C1711: [NO DATA] RL
• C1712: [CHECKSUM ERR] FL
• C1713: [CHECKSUM ERR] FR
• C1714: [CHECKSUM ERR] RR
• C1715: [CHECKSUM ERR] RL
• C1716: [PRESSDATA ERR] FL
• C1717: [PRESSDATA ERR] FR
• C1718: [PRESSDATA ERR] RR
• C1719: [PRESSDATA ERR] RL
• C1720: [CODE ERR] FL
• C1721: [CODE ERR] FR
• C1722: [CODE ERR] RR
• C1723: [CODE ERR] RL
• C1724: [BATT VOLT LOW] FL
• C1725: [BATT VOLT LOW] FR
• C1726: [BATT VOLT LOW] RR
• C1727: [BATT VOLT LOW] RL

2009 Pathfinder

BCM (BODY CONTROL MODULE)

ADP-149

< ECU DIAGNOSIS >

ADP

CONSULT display

Fail-safe

Intelligent Key

warning lamp ON

Tire pressure

monitor warning

lamp ON

Reference page

No DTC is detected.
further testing
may be required.

—

U1000: CAN COMM CIRCUIT

—

BCS-33

U1010: CONTROL UNIT (CAN)

—

BCS-34

B2013: STRG COMM 1

—

SEC-27

B2190: NATS ANTTENA AMP

—

SEC-30

(with I-

Key),

SEC-136

(without I-Key)

B2191: DIFFERENCE OF KEY

—

SEC-33

(with I-

Key),

SEC-139

(without I-Key)

B2192: ID DISCORD BCM-ECM

—

SEC-34

(with I-

Key),

SEC-140

(without I-Key)

B2193: CHAIN OF BCM-ECM

—

SEC-36

(with I-

Key),

SEC-142

(without I-Key)

B2552: INTELLIGENT KEY

—

SEC-38

B2590: NATS MALFUNCTION

—

SEC-39

C1708: [NO DATA] FL

—

WT-14

C1709: [NO DATA] FR

—

WT-14

C1710: [NO DATA] RR

—

WT-14

C1711: [NO DATA] RL

—

WT-14

C1712: [CHECKSUM ERR] FL

—

WT-16

C1713: [CHECKSUM ERR] FR

—

WT-16

C1714: [CHECKSUM ERR] RR

—

WT-16

C1715: [CHECKSUM ERR] RL

—

WT-16

C1716: [PRESSDATA ERR] FL

—

WT-18

C1717: [PRESSDATA ERR] FR

—

WT-18

C1718: [PRESSDATA ERR] RR

—

WT-18

C1719: [PRESSDATA ERR] RL

—

WT-18

C1720: [CODE ERR] FL

—

WT-16

C1721: [CODE ERR] FR

—

WT-16

C1722: [CODE ERR] RR

—

WT-16

C1723: [CODE ERR] RL

—

WT-16

C1724: [BATT VOLT LOW] FL

—

WT-16

C1725: [BATT VOLT LOW] FR

—

WT-16

C1726: [BATT VOLT LOW] RR

—

WT-16

C1727: [BATT VOLT LOW] RL

—

WT-16

C1729: VHCL SPEED SIG ERR

—

WT-19

C1735: IGNITION SWITCH

—

2009 Pathfinder

ADP-150

< SYMPTOM DIAGNOSIS >

ADP SYSTEM SYMPTOMS

SYMPTOM DIAGNOSIS

ADP SYSTEM SYMPTOMS

Symptom Table

INFOID:0000000003935603

NOTE:
Always perform the “Basic Inspection” before performing diagnosis in the following table. Refer to

ADP-5,

"Work Flow"

SYMPTOM 1

SYMPTOM 2

SYMPTOM 3

SYMPTOM 4

Symptom

Diagnosis procedure

Reference

page

Manual functions (for specific part) do
not operate

Sliding operation

Check sliding switch.

ADP-44

Reclining operation

Check reclining switch.

ADP-46

Lifting operation (front)

Check lifting switch (front).

ADP-48

Lifting operation (rear)

Check lifting switch (rear).

ADP-50

Pedal operation

1. Check pedal adjusting switch.

ADP-52

2. Check pedal adjusting sensor.

ADP-75

Door mirror operation

1. Changeover switch.

ADP-57

2. Mirror switch

ADP-59

All parts of seat

Check power seat switch ground cir-
cuit.

ADP-62

Symptom

Diagnosis procedure

Reference

page

Memory functions (for specific part) do
not operate

Sliding operation

Check sliding sensor.

ADP-67

Reclining operation

Check reclining sensor.

ADP-69

Lifting operation (front)

Check lifting sensor (front).

ADP-71

Lifting operation (rear)

Check lifting sensor (rear).

ADP-73

Pedal operation

Check pedal adjusting sensor.

ADP-75

Door mirror operation

Check door mirror sensor.

Driver side:

ADP-77

Passenger

side:

ADP-79

Symptom

Diagnosis procedure

Reference

page

Memory functions and manual func-
tions (for specific part) do not operate

Sliding operation

Check sliding motor.

ADP-81

Reclining operation

Check reclining motor.

ADP-83

Lifting operation (front)

Check lifting motor (front).

ADP-85

Lifting operation (rear)

Check lifting motor (rear).

ADP-87

Pedal operation

Check pedal adjusting motor.

ADP-89

Door mirror operation

Check door mirror motor.

ADP-91

2009 Pathfinder

ADP SYSTEM SYMPTOMS

ADP-151

< SYMPTOM DIAGNOSIS >

ADP

SYMPTOM 5

SYMPTOM 6

Symptom

Diagnosis procedure

Reference

page

Entry/Exit assist function does not operate.

1. Check system setting.

ADP-20

2. Perform initialization.

ADP-21

3. Check front door switch (driver side).

ADP-65

Intelligent Key interlock function does not operate.
(Other automatic operations and Intelligent Key system
are normal)

1. Check door lock function.

DLK-22

2. Perform memory storing.

ADP-10

Symptom

Diagnosis procedure

Reference

page

Memory indicators 1 and/or 2 do not illuminate.

1. Check seat memory switch.

ADP-55

2. Check seat memory indicator.

ADP-94

Symptom

Diagnosis procedure

Reference

page

Memory operation does not operate.

Check A/T device (park position switch).

ADP-63

2009 Pathfinder

ADP-152

< SYMPTOM DIAGNOSIS >

NORMAL OPERATING CONDITION

NORMAL OPERATING CONDITION

Description

INFOID:0000000003935604

The following symptoms are normal operations, and they do not indicate a malfunction.

Symptom

Cause

Action to take

Reference page

Entry/Exit assist function does
not operate.

No initialization has been performed.

Perform initialization.

ADP-19

Entry/exit assist function is disabled.
NOTE:
The entry/exit assist function is disabled
before delivery (initial setting).

Change the settings.

ADP-22

Entry assist function does not op-
erate.

Manual operation with power seat switch
was performed after exit assist function
excution.

Perform the memory

function.

ADP-22

Memory function, entry/exit as-
sist function or Intelligent Key in-
terlock function does not
operate.

The operating conditions are not fulfilled.

Fulfill the operation

conditions.

Memory function:

ADP-16

Exit assist function:

ADP-20

Entry assist function:

ADP-22

Intelligent Key interlock

function:

ADP-10

2009 Pathfinder

PRECAUTIONS

ADP-153

< PRECAUTION >

ADP

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000003935605

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.

Precaution Necessary for Steering Wheel Rotation After Battery Disconnect

INFOID:0000000004448898

NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-

TEM).

• Remove and install all control units after disconnecting both battery cables with the ignition knob in the

″

LOCK

″

position.

• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.

If DTC is detected, perform trouble diagnosis according to self-diagnostic results.

For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.

OPERATION PROCEDURE

Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.

Use the Intelligent Key or mechanical key to turn the ignition switch to the

″

ACC

″

position. At this time, the

steering lock will be released.

Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.

Perform the necessary repair operation.

When the repair work is completed, return the ignition switch to the

″

LOCK

″

position before connecting

the battery cables. (At this time, the steering lock mechanism will engage.)

Perform a self-diagnosis check of all control units using CONSULT-III.

Precaution for Work

INFOID:0000000003935606

• When removing or disassembling each component, be careful not to damage or deform it. If a component

may be subject to interference, be sure to protect it with a shop cloth.

2009 Pathfinder

ADP-154

< PRECAUTION >

PRECAUTIONS

• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component

with a shop cloth or vinyl tape to protect it.

• Protect the removed parts with a shop cloth and keep them.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After re-installation is completed, be sure to check that each part works normally.
• Follow the steps below to clean components.
- Water soluble foul: Dip a soft cloth into lukewarm water, and wring the water out of the cloth to wipe the

fouled area.
Then rub with a soft and dry cloth.

- Oily foul: Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%), and wipe

the fouled area.
Then dip a cloth into fresh water, and wring the water out of the cloth to wipe the detergent off. Then rub with
a soft and dry cloth.

• Do not use organic solvent such as thinner, benzene, alcohol, or gasoline.
• For genuine leather seats, use a genuine leather seat cleaner.

2009 Pathfinder

Content .. 18 19 20 21 ..
