INSPECTION AND ADJUSTMENT EC-21 < BASIC INSPECTION > [VQ40DE] C D E F G H I J K L M A EC N P O 2. Rev engine (2,000 to 3,000 rpm) two or three times under no 3. Read idle speed in “DATA MONITOR” mode with CONSULT-III. EC-24, "Idle Speed and Ignition Timing Check" . Without CONSULT-III 1. Run engine at about 2,000 rpm for about 2 minutes under no load. 2. Rev engine (2,000 to 3,000 rpm) two or three times under no load, then run engine at idle speed for about 3. EC-24, "Idle Speed and Ignition Timing Check" . OK or NG OK >> GO TO 10. NG >> GO TO 4. 4. PERFORM ACCELERATOR PEDAL RELEASED POSITION LEARNING 1. Stop engine. 2. EC-26, "Accelerator Pedal Released Position Learning" >> GO TO 5. 5. PERFORM THROTTLE VALVE CLOSED POSITION LEARNING Perform EC-26, "Throttle Valve Closed Position Learning" . >> GO TO 6. 6. PERFORM IDLE AIR VOLUME LEARNING EC-26, "Idle Air Volume Learning" Is Idle Air Volume Learning carried out successfully? Yes or No Yes >> GO TO 7. No >> 1. Follow the instruction of Idle Air Volume Learning. 2. GO TO 4. 7. CHECK TARGET IDLE SPEED AGAIN With CONSULT-III 1. Start engine and warm it up to normal operating temperature. 2. Read idle speed in “DATA MONITOR” mode with CONSULT-III. EC-24, "Idle Speed and Ignition Timing Check" . Without CONSULT-III 1. Start engine and warm it up to normal operating temperature. PBIA8513J 625 ± 50 rpm (in P or N position) 625 ± 50 rpm (in P or N position) 625 ± 50 rpm (in P or N position) |
